Name: Dehner Elektronik SYS 1548-5012-T3 Bench PSU (fixed voltage) 12 V DC 4.17 A 50 W Regulated
Brand: Dehner Elektronik
SKU: 2201344
Availability: InStock

Highlights & Details

Dehner Elektronik SYS 1548-5012-T3 Bench PSU (fixed voltage) 12 V DC 4.17 A 50 W Regulated

Protection class 1 (with protective earth conductor)
Efficiency – Level VI.
Overvoltage protection
Overload protection
Short-circuit protection
EN 62368-1

Technical specifications

Product type: Bench PSU (fixed voltage)

Used at: Indoors

Max. output current: 4.17 A

Output current (max.) - rounded: 4.17 A

Output: 5.5/2.1 coaxial connector

Output voltage: 12 V DC

Input voltage: 90 V AC
264 V AC

No. of outputs: 1 x

Type: Bench power supply unit

EuP Status: Step 2

Weight: 290 g

: 50 W

PSU features: Regulated

Type: Switched PSU

Width: 55 mm

Height: 35 mm

Length: 115 mm

Type: SYS 1548-5012-T3

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2201344 Dehner Elektronik SYS 1548-5012-T3 Bench PSU (fixed voltage) 12 V DC 4.17 A 50 W Regulated

Conformity certificate

Conformity certificate 2201344 Dehner Elektronik SYS 1548-5012-T3 Bench PSU (fixed voltage) 12 V DC 4.17 A 50 W Regulated

Warranty Terms

Warranty Terms 2201344 Dehner Elektronik SYS 1548-5012-T3 Bench PSU (fixed voltage) 12 V DC 4.17 A 50 W Regulated

Description

Powerful compact desktop power supply. Ideal for different applications. The power supply is suitable for continuous operation and offers a maximum of safety through the various protective measures. The power supply complies with the latest international energy saving guidelines.

Due to the wide-range input from 100V/AC to 240V/AC, it is suitable for worldwide use. The output voltage is stabilised. The switched-mode power supply has a high degree of efficiency and thus a low heat generation.

This text is machine translated.

Scope of delivery

Connection cable
User manual
