Name: Digitus DN-19 09-U-S-1 19" wall cabinet (W x H x D) 520 x 512 x 400 mm 9 U Grey-white (RAL 7035)
Brand: Digitus
SKU: 703932
Availability: InStock

A white metal cabinet with a glass door and ventilation openings on the top, often used for storing electronic equipment.

White mattress packed in a rectangular box, secured with two black plastic straps.

1/2

Datasheet (PDF)

Fast track dispatch on Fri 16 Oct

36 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 91.99 / piece)

€ 91.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

SoHo Wall Mounting Cabinet, unmounted - 540x400 mm (WxD)

The DIGITUS® Compact Series is made for high demand IT-Infrastructure Solutions - designed and developed on highest standard in Germany

Technical specifications

Product type: 19" wall cabinet

Rack unit: 9 U

Width: 520 mm

Height: 512 mm

Depth: 400 mm

Material: Safety glass
Steel

Dim: (W x H x D) 520 x 512 x 400 mm

Weight: 12 kg

Factory colour: Grey-white (RAL 7035)

Rack size: 483 mm (19")

Wireless charging: No

UKCA: yes

Plastic free packaging: Plastic-free packaging

Documents & Downloads

Datasheet

Datasheet 703932 Digitus DN-19 09-U-S-1 19" wall cabinet (W x H x D) 520 x 512 x 400 mm 9 U Grey-white (RAL 7035)

User & Safety Instructions

User & Safety Instructions 703932 Digitus DN-19 09-U-S-1 19" wall cabinet (W x H x D) 520 x 512 x 400 mm 9 U Grey-white (RAL 7035)

Description

The DIGITUS® Compact Series is a range of 19" wall mount enclosures developed for installation of both cabling and equipment. The enclosures are special designed to save a lot of space and are ideal for use a wide range of applications in the 19" area. The enclosures are designed for an optimal performance and come with a lot of features like quick release front door and fully adjustable profiles. The access on the top and the base of each cabinet makes the installation of the cabling very flexible, easy and time-saving. A full range of DIGITUS® accessories are available to complete the installation of the wall mounting cabinets with professional products.

· 1.5 mm strong sheet steel with high load capacity, powder coated
· IP 20
· Ventilation slots for active and passive ventilation and exhaustion
· Lockable Safety-glass door
· Unmounted, flat package

Features

Protection class: IP20Lockable safety glass door200° door opening angle1-point lock on the front door483 mm (19") rails mounted on the front inside the cabinet, galvanizedDepth adjustable with 483 mm (19 ") rails1.1 - 1.5 strong steel sheet with a high load capacity, powder-coatedCable input with brush strip in the roof and with plastic cover in the groundRoof is prepared for receiving a fan element (punched pictures)Ventilation slots for active and passive ventilationMounting depth for components min.-max. 170-270 mmWidth 540 mmColour: Light gray, RAL 7035Front door: Glass door, single-leafHE 9Cabinet type: Wall housingSide walls: Both sidesDepth: 400 mm60 kg load capacityIP protection class IP20Mounted: No.
