Diotec PB1001 Diode bridge KBPC8-PB10 100 V 5 A

Two black rectifier bridges, each with four terminals, one lying flat and the other standing vertically.
Image similar
Product type
Diode bridge
Enclosure
KBPC8-PB10
U(RRM)
100 V
Forward current I(F)
5 A
Forward voltage U(F)
1.20 V
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
109 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Minimum order quantity: 2
Total (€ 1.13208 / piece)
€ 2.26
prav.tax.untaxed incl. VAT
plus € 0.02
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

  • Type wire-leadHousing KBPC8-PB10Periodic Peak Reverse Voltage - VRRM 100 VContinuous current - IFAV 10.00 AJunction temperature - Tjmax 150 °CReverse delay time - trr: NsSurge current - IFSM 135.00 AForward voltage - VF 1.20 VIF 5.00 AReverse current - IR 5,000 µAVR 100 VLock layer capacity - CJ: PFVR V
Type

PB1001

Product type

Diode bridge

Enclosure

KBPC8-PB10

Manufacturer

Diotec

Manuf. code

DIO

U(RRM)

100 V

Forward current I(F)

5 A

Forward voltage U(F)

1.20 V

Forward voltage reference

5.00 A

I(FSM) 50Hz

135 A

Reverse leakage current I(r)

5 µA

Reverse leakage current I(r) reference

100 V

Operating temperature (max.)

150 °C

Mounting type

Through-hole mounting

RoHS-compliant

Yes

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 2810464 Diotec PB1001 Diode bridge KBPC8-PB10 100 V 5 A
