Image similar
Image similar
Diotec PB1004 Diode bridge KBPC8-PB10 400 V 5 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
20
-
€ 1.04978
60
8% = € 0.08
€ 0.96528
100
11% = € 0.12
€ 0.93147
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 20
Total (€ 1.04978 / piece)
€ 21.00
plus VAT.
Technical specifications
- Type wire-leadHousing KBPC8-PB10Periodic Peak Reverse Voltage - VRRM 400 VContinuous current - IFAV 10.00 AJunction temperature - Tjmax 150 °CReverse delay time - trr: NsSurge current - IFSM 135.00 AForward voltage - VF 1.20 VIF 5.00 AReverse current - IR 5,000 µAVR 400 VLock layer capacity - CJ: PFVR V
- Type
PB1004
- Enclosure
KBPC8-PB10
- Manufacturer
Diotec
- U(RRM)
400 V
- Forward current I(F)
5 A
- Forward voltage U(F)
1.20 V
- Forward voltage reference
5.00 A
- I(FSM) 50Hz
135 A
- Reverse leakage current I(r)
5 µA
- Reverse leakage current I(r) reference
400 V
- Operating temperature (max.)
150 °C
- Mounting type
Through-hole mounting
- RoHS-compliant
Yes
- Product type
Diode bridge
Documents & Downloads
Datasheet
Datasheet 2810466 Diotec PB1004 Diode bridge KBPC8-PB10 400 V 5 A
User & Safety Instructions
User & Safety Instructions 2810466 Diotec PB1004 Diode bridge KBPC8-PB10 400 V 5 A
Description
Rectifiers from leading manufacturers. Full details free to download from our comprehensive product documents library.
