DSSERVO Custom servo DSSERVO BLS3375 Brushless Metal
- Extremely powerful - up to 82kgcm at 0.11sec/60°
- Brushless motor in a robust full metal casing
- Extended height (40.5mm) for maximum performance
- IP67 certified - water and dust-proof
- Double ball bearing for uniform movement
- 270° steering angle possible (PWM-controlled)
- Suitable for operating voltages up to 8.4V
- This text is machine translated.
Technical specifications
- Model
DSSERVO BLS3375
- Dim
(L x W x H) 40 x 20 x 40.5 mm
- Length
40 mm
- Width
20 mm
- Height
40.5 mm
- Weight
85 g
- Actuation time at 4.8 V
0.17 sec/60°
- Actuation time at 6 V
0.14 sec/60°
- Actuation time (7.4 V)
0.12 sec/60°
- Type of bearing
Double ball bearing
- Manufacturer part #
DS019
- Min. operating voltage
4.8 V
- Operating voltage
4.8 - 8.4 V
- Max. operating voltage
8.4 V
- Product type
Custom servo
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3773691 DSSERVO Custom servo DSSERVO BLS3375 Brushless Metal
Description
Scope of delivery
- DS servo
