Eaton EP-401401 Power supply unit 24 V 40 A 1016 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 719.00 / piece)
€ 719.00
incl. VAT
14-day return policy included
Highlights & Details
Power supply, three-phase, 320 - 575 V AC / 24 V DC, 40 A
- Output 24 V / 40 A
- Power 1016 W
- Screws
Technical specifications
- Type
Three phases
- Product type
Power supply unit
- Input voltage (max.)
575 V
- Max. output current
40 A
- Output current (max.) - rounded
40 A
- Min. input voltage
320 V
- Dim
(L x W x H) 124 x 110 x 128.7 mm
- Output voltage (max.)
24 V
- Connection
Screws
1016 W
- Input frequency
50/60 Hz
IP20
- Operating temperature (max.)
70 °C
- Operating temperature (min.)
-25 °C
- Operating temperature
-25 °C - 70 °C
- Weight
2.26 kg
- Width
110 mm
- Height
128.7 mm
- Length
124 mm
- Type
PSG960F24SMB
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3553272 Eaton EP-401401 Power supply unit 24 V 40 A 1016 W
User & Safety Instructions
User & Safety Instructions 3553272 Eaton EP-401401 Power supply unit 24 V 40 A 1016 W
Description
Features
- Inaccessible internal input fuse (T4 AH/500 V) for device protection
