econ connect SIL socket (standard) No. of rows: 1 Pins per row: 12 BLG1X12-1 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 0.31
30
6% = € 0.02
€ 0.29
50
13% = € 0.04
€ 0.27
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 0.31 / piece)
€ 3.10
plus VAT.
Highlights & Details
Socket connector, straight RM 2.54 mm
- Content 1 pc(s)
- No. of rows 1
- Pins per row 12
Technical specifications
- Connector type
Power strip, straight
- No. of rows
1
- Pins per row
12
- Total number of pins
12
- CS
2.54 mm
- Connection
Print
- Factory colour
Black
- Pin shape
Rectangular
- Nominal voltage
1000 V AC
- Nominal current
3 A
- Nominal current - rounded value
3 A
- Contact surface
Gold plated
- Contact material
Copper alloy
- Case material
PBT, UL94V-0
- Pin Ø
0.64 mm
- Pin length (PCB)
3.15 mm
- Separable
No
- Dim
(L x W x H) 30.98 x 30.98 x 8.5 mm
- Connector orientation
Perpendicular (to the PCB)
- Manufacturer part #
BLG1X12-1
- Content
1 pc(s)
- Height
8.5 mm
- Length
30.98 mm
- Width
30.98 mm
- Industrial packaging
No
- Type
BLG1X12-1
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Product type
SIL socket (standard)
Documents & Downloads
Datasheet
Datasheet 1492269 econ connect SIL socket (standard) No. of rows: 1 Pins per row: 12 BLG1X12-1 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1492269 econ connect SIL socket (standard) No. of rows: 1 Pins per row: 12 BLG1X12-1 1 pc(s)
