Name: econ connect SIL socket (standard) No. of rows: 1 Pins per row: 5 BL5/1G8 1 pc(s)
Brand: econ connect
SKU: 1303431
Availability: InStock

A black, rectangular pin header with golden pins, used for electrical connections on printed circuit boards.

Technical drawing of a connector with dimensions and labels indicating spacing and contact count, side and top view.

1/2

Image similar

Connector type

Power strip, straight

Product type

SIL socket (standard)

No. of rows

Total number of pins

2.54 mm

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

660 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 20

Total (€ 0.20 / piece)

€ 4.00

incl. VAT

14-day return policy included

Report legal concerns

Alternative article by TRU COMPONENTS

TRU COMPONENTS SIL socket (standard) No. of rows: 1 Pins per row: 5 TC-2506419 1 pc(s)

€ 0.28

incl. VAT plus

Highlights & Details

Socket strip RM 2.54 mm

Content 1 pc(s)
No. of rows 1
Pins per row 5

Our service for you

Technical specifications

Connector type: Power strip, straight

Product type: SIL socket (standard)

No. of rows: 1

Pins per row: 5

Total number of pins: 5

CS: 2.54 mm

Connection: Print

Factory colour: Black

Pin shape: Rectangular

Nominal voltage: 500 V AC

Nominal current: 1 A

Nominal current - rounded value: 1 A

Contact surface: Gold plated

Contact material: Copper alloy

Case material: PBT

Pin length (PCB): 3 mm

Separable: No

Dim: (L x W x H) 13.20 x 11.50 x 2.54 mm

Connector orientation: Perpendicular (to the PCB)

Manufacturer part #: BL5/1G8

Industrial packaging: No

Content: 1 pc(s)

Width: 11.50 mm

Height: 2.54 mm

Length: 13.20 mm

RoHS-compliant: Yes

Max. temperature: +105 °C

Min. temperature: -40 °C

Type: BL5/1G8

Variants(All information include VAT, plus shipping costs)

Nominal current - rounded value

Connector type

No. of rows

Total number of pins

Pin Ø

econ connect SIL socket (standard) No. of rows: 1 Pins per row: 10 BLG1X10 1 pc(s)

Item no:1492266

Fast track dispatch on Wed 14 Oct

1938 Piece(s)Conrad Electronic

3 A

Power strip, straight

0.64 mm

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.30^*

econ connect SIL socket (standard) No. of rows: 1 Pins per row: 10 BLW1X10 1 pc(s)

Item no:1492358

Fast track dispatch on Wed 14 Oct

674 Piece(s)Conrad Electronic

3 A

Power strip, right angle

0.64 mm

Piece(s)

Minimum order quantity: 15

Multiple: 1

€ 0.20^*

econ connect SIL socket (standard) No. of rows: 1 Pins per row: 11 BLG1X11 1 pc(s)

Item no:1492304

Fast track dispatch on Wed 14 Oct

243 Piece(s)Conrad Electronic

3 A

Power strip, straight

0.64 mm

Piece(s)

Minimum order quantity: 15

Multiple: 1

€ 0.23^*

econ connect SIL socket (standard) No. of rows: 1 Pins per row: 12 BLG1X12-1 1 pc(s)

Item no:1492269

Fast track dispatch on Wed 14 Oct

1085 Piece(s)Conrad Electronic

3 A

Power strip, straight

0.64 mm

Piece(s)

Minimum order quantity: 10

Multiple: 1

€ 0.37^*

econ connect SIL socket (standard) No. of rows: 1 Pins per row: 13 BLG1X13 1 pc(s)
