ETI Elektrotechnik 002540203 EFH 10 DC 2p Fuse holder Suitable for Micro fuse 10.3 x 38 mm 25 A 1000 V 1 pc(s)
Product type
Fuse holder
Nominal voltage
1000 V
Nominal current - rounded value
25 A
Mounting type
DIN rail
Suitable for
Micro fuse 10.3 x 38 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 12.99 / piece)
€ 12.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
Fuse holder
- Nominal voltage
1000 V
- Nominal current
25 A
- Nominal current - rounded value
25 A
- Factory colour
White
- Mounting type
DIN rail
- Suitable for
Micro fuse 10.3 x 38 mm
- Cross section
25 mm²
- Number of fuses
2
- Min. temperature
-5 °C
- Max. temperature
+40 °C
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
EFH 10 DC 2p
Documents & Downloads
Datasheet
Datasheet 3304298 ETI Elektrotechnik 002540203 EFH 10 DC 2p Fuse holder Suitable for Micro fuse 10.3 x 38 mm 25 A 1000 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3304298 ETI Elektrotechnik 002540203 EFH 10 DC 2p Fuse holder Suitable for Micro fuse 10.3 x 38 mm 25 A 1000 V 1 pc(s)
Description
Features
- Classification name: Fuse socket
- Rated current (A): 25
- Number of pins: 2
- STANDARD IEC 60947-1, IEC 60947-3, UL 4248-1, UL 4248-19
- For use with CH gPV-fuse links
- Size: 10x38mm
- Rated voltage DC: 1000V
- Application: Photovoltaic-installation
- UL-certificate E356295
- Product group: Fuse base
- Usage category: DC-20B
- Connect 1 - 25 mm2
- Mounting 35mm DIN rail
- Group: LV fuse disconnect switch
- Ambient temperature (°C): -5 to +40°C.
- This text is machine translated.
