ElectromechanicsFusesFuse Holders

ETI Elektrotechnik 002540211 EFH 10 DC 1p LED Fuse holder incl. status indicator Suitable for Micro fuse 10.3 x 38 mm 25

A white circuit breaker with a pink detail and technical inscription. Suitable for electrical applications up to 25A at 1000V.
ETI Elektrotechnik 002540211 EFH 10 DC 1p LED Fuse holder incl. status indicator Suitable for Micro fuse 10.3 x 38 mm 25-1
1/2
Product type
Fuse holder
Nominal voltage
1000 V
Nominal current - rounded value
25 A
Mounting type
DIN rail
Suitable for
Micro fuse 10.3 x 38 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
54 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 12.99 / piece)
€ 12.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Product type

Fuse holder

Features

incl. status indicator

Nominal voltage

1000 V

Nominal current

25 A

Nominal current - rounded value

25 A

Factory colour

White

Mounting type

DIN rail

Suitable for

Micro fuse 10.3 x 38 mm

Cross section

25 mm²

Number of fuses

1

Min. temperature

-5 °C

Max. temperature

40 °C

Length

38 mm

Height

38 mm

(Ø)

10.3 mm

Content

1 pc(s)

Dim

(Ø x H) 10.3 mm x 38 mm

RoHS-compliant

Yes

Type

EFH 10 DC 1p LED

Documents & Downloads

Datasheet

Datasheet 3304297 ETI Elektrotechnik 002540211 EFH 10 DC 1p LED Fuse holder incl. status indicator Suitable for Micro fuse 10.3 x 38 mm 25

User & Safety Instructions

User & Safety Instructions 3304297 ETI Elektrotechnik 002540211 EFH 10 DC 1p LED Fuse holder incl. status indicator Suitable for Micro fuse 10.3 x 38 mm 25

Description

Features

  • Classification name: Fuse socket
  • Rated current (A): 25
  • Number of pins: 1
  • STANDARD IEC 60947-1, IEC 60947-3, UL 4248-1, UL 4248-19
  • For use with CH gPV-fuse links
  • Size: 10x38mm
  • Rated voltage DC: 1000V
  • LED indicator
  • Application: Photovoltaic-installation
  • UL-certificate E356295
  • Product group: Fuse base
  • Usage category: DC-20B
  • Connect 1 - 25 mm2
  • Mounting 35mm DIN rail
  • Group: LV fuse disconnect switch
  • Ambient temperature (°C): -5 to +40°C.
