Highlights & Details

Technical specifications

Coil characteristics: 110/120 V/AC 50/60 Hz, pick-up power 2.3 VA, holding power 1.7 VA
Material: copper, steel, thermoplastic solenoid

Product type: Magnet coil

Enclosure material: PA
Steel

Connection: Circuit diagram

Manufacturer part #: 8025334

Type: Electrical connection: connection Image Form C

: IP65

Max. ambient temperature: +50 °C

Min. ambient temperature: -10 °C

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2124662 FESTO Magnet coil 8025334 VACS-C-C1-16B Circuit diagram 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2124662 FESTO Magnet coil 8025334 VACS-C-C1-16B Circuit diagram 1 pc(s)

Information

Information 2124662 FESTO Magnet coil 8025334 VACS-C-C1-16B Circuit diagram 1 pc(s)

Description

Solenoid VACS-C-C1-16B Connection Diagram Form C, according to EN 175 301, 120 V AC/60 Hz and 110 V AC/50-60 Hz. Installation position=any, switch-on duration = 100%, insulation class=H, coil characteristics = 110/120 V AC 50/60Hz, pick-up power 2.3 VA, holding power 1.7 VA, impulse withstand voltage = 2.5 kV

This text is machine translated.

Hints

The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min

Description

Solenoid VACS-C-C1-16B Connection Diagram Form C, according to EN 175 301, 120 V AC/60 Hz and 110 V AC/50-60 Hz. Installation position=any, switch-on duration = 100%, insulation class=H, coil characteristics = 110/120 V AC 50/60Hz, pick-up power 2.3 VA, holding power 1.7 VA, impulse withstand voltage = 2.5 kV

This text is machine translated.

Hints

The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
