Buy M & M International Directly actuated pneumatic valve D 263DVH G 1/4 OFF/NC 1 pc(s) | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

A stable valve mechanism made of brass and steel with a rotary handle on top. Used in water and gas pipelines to regulate flow.

A stable valve mechanism made of brass and steel with a rotary handle on top. Used in water and gas pipelines to regulate flow.

M & M International

EAN:

Part number:

Item no:

Fast track dispatch on Mon 2 Nov

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 46.99 / piece)

€ 46.99

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Product type: Directly actuated pneumatic valve

Max. operating pressure: 8 bar

Enclosure material: Brass

Connection: G 1/4

Operating medium: Water, neutral fluids as well as air and gas

Operating temperature: + 50 °C (max)

Media temperature (range): -10 up to +90 °C

Manufacturer part #: D 263DVH

Max. operating temperature: + 50 °C

Sealant: NBR

Function: 2/2-way

Max. media temperature: +90 °C

Media temperature (min.): -10 °C

Medium: Inert gases
Inert liquids

Features: P port connector (G1/4)

: IP65

Operating principle: OFF/NC

KV value: 4.5

Material (details): Valve body: Brass · Seal: NBR

Operating voltage: Optional coil

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 583237 M & M International Directly actuated pneumatic valve D 263DVH G 1/4 OFF/NC 1 pc(s)

Description

High quality solenoid valve from M&M in modular design Thus you have yet wider range of valves and primarily in coils, which are now offered in all major operating voltages, such as 12 V DC, 24 V / DC, 24 V / AC and 230 V / AC. Another advantage of the modular design is that now the defective coils can be bought separately as replacement and can be easily exchanged. Thus an expensive removal and installation of the valve is not necessary anymore

Hints

The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min

Description

High quality solenoid valve from M&M in modular design Thus you have yet wider range of valves and primarily in coils, which are now offered in all major operating voltages, such as 12 V DC, 24 V / DC, 24 V / AC and 230 V / AC. Another advantage of the modular design is that now the defective coils can be bought separately as replacement and can be easily exchanged. Thus an expensive removal and installation of the valve is not necessary anymore

Hints

The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
