Motion sensor in a rectangular housing, suitable for automatic light control in outdoor areas.

'Detailed technical drawing of a connector plug. Shows dimensions: width 68.7 mm, height 31.5 mm, depth 18.11 mm.'

1/2

Product type

IR motion detector

Max. operating voltage

230 V AC

Contact type

1 maker

Max. range

8 m

Content

1 pc(s)

Datasheet (PDF)

Fast track dispatch on Wed, 23 Sep

5 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 30.24 / piece)

€ 30.24

plus VAT.

Only 5 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Finder 18.11.8.230.0000

Suitable for installation outdoors, meets IP54
Particularly suitable for wall installation
Adjustable ambient light intervention threshold
Adjustable Light On Time
Universal mounting position - permits the
selection of any area for survey
Wide angle of survey

Technical specifications

Nominal lamp rating: incandescent/halogen 1000 W / Fluorescent lamp with Electronic ballast 500 W / Fluorescent lamp with Electromecanical ballast 350 W / CFL 300 W / LED 230 V 300 W / Halogen or LV LED with electronic ballast 300 W / Halogen or LV LED with electromechanical ballast 500 W

Product type: IR motion detector

Content: 1 pc(s)

Type: 18.11.8.230.0000

Operating voltage: 230 V AC

Operating voltage: 120 - 230 V AC

Min. operating voltage: 120 V AC

Max. operating voltage: 230 V AC

Contact type: 1 maker

Contact material: AgSnO2

Switching voltage (max.): 230 V AC

Switching current (max.): 10 A

Max. switching capacity: 2300 VA

Electrical lifespan: 100 x 10³ cycles

Light sensitivity (min.): 5 lx

Light sensitivity (max.): 350 lx

Angular aperture: 110°

: 8 m

Time range (min.): 10 s

Time range (max.): 12 min

Min. temperature: -30 °C

Max. temperature: +50 °C

Factory colour: White

Type: Installation in external areasIP54

Sensitivity: 1 - 500 lx

Nominal voltage (details): 250 V/AC

Switching capacity: (AC1) 2500 VA/ (AC15) 450 VA

Switching voltage: 250 V/AC/ 400 V/AC

Switching current: 10 A

Type: 18/11/08.230.0000

Temperature range: -30 - +50 °C

Time range: 12 s - 35 min

Operating voltage: 110 - 230 V/AC

: Surface mounted (plaster)

: White

: 49

: Movement sensor

: TRUE

: 118.5 mm

: 68.7 mm

: Screwed terminal

: Untreated

: AC

: 50-60 MHz

: TRUE

: Thermoplastic

: 100 A

: Plastic

: 9010

: 120-230 V

: IP54

: FALSE

: Matt

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

: FALSE

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 503129 Finder 18.11.8.230.0000

User & Safety Instructions

User & Safety Instructions 503129 Finder 18.11.8.230.0000

Description

Motion detector for the installation in the outdoor area with protection class IP54.

This text is machine translated.

Features

Adjustable ambient light intervention threshold, Adjustable Light On Time

Scope of delivery

Mounting accessories are included in the packaging.

Hints

Approvals: EAC, IMQ.
