Fluke 6500-2 Electrical tester VDE standard 0413
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 2,475.00 / piece)
€ 2,475.00
incl. VAT
14-day return policy included
Highlights & Details
Fluke 6500-2 portable device tester according to DIN VDE 0701-0702 at programming mode
- Fast, one-button operation.
- Lightweight
- Robust
Technical specifications
- Product type
Electrical tester
Manufacturer's standards (no certificate)
- Reading category
CAT II 300 V
- Interfaces
USB
- Dim
(L x W x H) 200 x 275 x 114 mm
- Weight
3.13 kg
- Reading range (VDE)
Earth leakage resistance
Insulation resistance
Leakage current
Continuity
Touch voltage
Voltage
Current
Power
- DIN standard
DIN EN 61557
- Display type
Digital (LCD)
- Width
275 mm
- Height
114 mm
- Length
200 mm
- Test procedure
manual
- Voltage supply
230 V/AC
- Memory (space)
1000
- Memory
Yes
- Type
6500-2
- VDE standard
0413
- Features
incl. case
RCD/FI testing
- Memory
1000 internal records
- Display (details)
LCD
- Interfaces
USB
- Standards
EN61557-1: 1997, EN61557-2: 1997, EN61557-4: 1997, EN61557-6: 1997, DIN VDE0404-2
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1152485 Fluke 6500-2 Electrical tester VDE standard 0413
User & Safety Instructions
User & Safety Instructions 1152485 Fluke 6500-2 Electrical tester VDE standard 0413
Description
The device tester Fluke 6500-2 is characterised by low weight, small size, one-button operation and improved automatic tests. In this way, you can increase the number of tests on mobile devices per day. With the device tester 6500-2, measurements can be carried out without loss of quality in the results faster. Each of the pre-test routines by pressing one key. This is much easier than the device via menu or the selection of multiple functions and enables faster and more efficient working. The model 6500-2 is also equipped with custom test routines and alphanumeric keyboard for fast data entries. The portable device tester 6500-2 is extremely compact and can easily be carried when working on site. The enclosed stable hard-shell case protects the device during transport and also offers space for accessories and other devices. This portable device tester is - as all devices from Fluke - robust and designed for use on site. With a portable device tester from Fluke, they have a universal solution with all functions for testing of portable devices.
This text is machine translated.
This text is machine translated.
Features
- One-button operation: Each test function is started via a special button
- Conforms to the new standards DIN EN 50678 (VDE 0701) and DIN EN 50699 (VDE 0702)
- Preset values for good/bad allow time savings
- Large backlit display for easy reading
- Single mains socket for connecting devices
- Separate IEC power socket for easy testing of cold equipment lines
- Detachable test leads for rapid on-site replacement
- Built-in handle
- USB port for data transfer
- Integrated keyboard for fast data entry
- Storage of measurement data on USB storage media and transfer to a PC
- Large graphic display with backlighting
- Pre-set automatic test sequences for increased user-friendliness
- Faster data entry with integrated codes for location, measurement point, and description
- Memory check function for more on-site control
- USB port for data transfer.
- This text is machine translated.
Scope of delivery
- Portable device tester Fluke 6500-2
- Quick instructions
- Hard plastic carrying case
- Test lead
- Probe tip
- Alligator clip
- Quick Reference Card
- Safety information.
