GDM Series right-angle connector Black GDM 3016 Pins:3 + PE 934 395-100-200 Hirschmann Content: 200 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Total (€ 289.92 / piece)
€
Technical specifications
- Connectable cables PG 9 Ø 4.5 - 7 mm
- PG 11 Ø 6 - 9 mm
- Pins
3 + PE
- Content
200 pc(s)
- Total no. of pins
3 + PE
- Factory colour
Black
- Industrial packaging
Yes
IP65
- Leading contact (PE)
Yes
- Manufacturer part #
934 395-100-200
- Type
GDM 3016
- Number of pins
3
- Operating current
- Nominal voltage (details)
250 V
- Nominal current (details)
16 A
- Contamination level
3
- Connection
Screw connection/cable lug/eyelet
- Temperature range
-40 - +125 °C
- RoHS-compliant
- Operating voltage
- Product type
Documents & Downloads
Datasheet
Datasheet 1718645 GDM Series right-angle connector Black GDM 3016 Pins:3 + PE 934 395-100-200 Hirschmann Content: 200 pc(s)
User & Safety Instructions
User & Safety Instructions 1718645 GDM Series right-angle connector Black GDM 3016 Pins:3 + PE 934 395-100-200 Hirschmann Content: 200 pc(s)
Description
Hirschmann actuator/connector to DIN EN 175301-803 ISO 4400 standard. Robust right-angle socket, dustproof and shockproof. Possible applications: Heating systems, gas/oil burner control systems, devices and components subject to vibration.
