Gedore 3549-05 UK 2958023 Torque wrench 3/8" (10 mm) 10 - 50 Nm
EAN:
Part number:
Item no:
10 Piece(s)
Sales and shipping:
Number
Total (€ 117.64 / piece)
€ 134.45
-13 %
€
Only 10 Piece(s) available
Highlights & Details
TORQUE WRENCH TORCOFLEX UK - 1-200 N·m
- Adjustable, triggering and robust pipe torque wrench with integrated lever change-over ratchet with square drive for industry and trade
- Classified according to DIN EN 6789:2017 Type II Class A, with a traceable factory certificate. Calibrated for a permissible deviation of +/- 3 % and better.
- For the controlled right suit
- This text is machine translated.
Technical specifications
- Distance between housing and square center: 17.5 mm
- Drive type/drive: Lever-change ratchet
- Drive square: 10 mm
- Number of teeth: 32
- Tightening direction: Right
- Trigger mechanism: Short travel trigger
- Calibration length: 270.5 mm
- Head width: 35 mm
- Head height: 19.1 mm
- Material: Steel tube construction with high-quality plastic parts
- Reversion angle: 11.25 °
- Output square: Ball lock
- Scaletype: Mono
- Product type
Torque wrench
- Downforce
3/8" (10 mm)
- Torque (min.)
10 Nm
- Torque (max.)
50 Nm
- Trigger accuracy
3 %
- Graduation
2.5°
- Length
348 mm
- DIN standard
DIN EN ISO 6789
- Weight
825 g
- Width
34 mm
- Height
34 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2290061 Gedore 3549-05 UK 2958023 Torque wrench 3/8" (10 mm) 10 - 50 Nm
