H-Tronic 1114620 WPS 3000 plus Liquid level gauge Filling, Draining 10.00 m
EAN:
Part number:
Item no:
151 Piece(s)
Do your needs go beyond this?
Sales and shipping:
Number
Total (€ 57.13 / piece)
€
Highlights & Details
Water level sensor WPS 3000 Plus
- With 2 sensors
- Switching point can be selected freely
- For all storage made of concrete, plastic or metal
- Switching output can be configured as NC/NO
Technical specifications
- Product type
Liquid level gauge
- Function
Filling
Draining
- Contact type
1 change-over
- Nominal voltage
230 V
- Switching current (max.)
13 A
- Material
Plastic
- Min. temperature
-15 °C
- Max. temperature
40 °C
- Cable length
10.00 m
IP20
- Dim
(L x W x H) 60 x 160 x 80 mm
- Length
60 mm
- Width
160 mm
- Height
80 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1057344 H-Tronic 1114620 WPS 3000 plus Liquid level gauge Filling, Draining 10.00 m
Information
Information 1057344 H-Tronic 1114620 WPS 3000 plus Liquid level gauge Filling, Draining 10.00 m
Description
The WPS3000plus electronic level differential switch is suitable for automatic level monitoring of conductive liquids in containers, wells, water tanks or the like. The device can be configured as either a refill or as a discharge device with a slider on the front. The liquid level is automatically measured between two water sensors (min. And Max) are held. Upon penetration of water or the reach of a certain level, a relay attracts and switches, for example, mains-operated pumps, valves or warning devices on and off. Suitable for all concrete, plastic or metal memories and installed quickly since all connections are plug-in. Due to the omission of moving float switches it works absolutely disturbance-free. Switching point selectable at any water level The switching output (relay) can be configured as NC or NO contact via switch on the front side. Teledetection up to 25 m over two core line No dangerous mains voltage at the sensor. Operation without operation or monitoring. Very easy and quick mounting, as plug-in ready. LED-displays for power, level and relay on.
