Name: HELU F-C-PURö-JZ Control lead 3 G 0.50 mm² Grey 21201 100 m
Brand: HELU
SKU: 1973005
Availability: InStock

A multi-core cable with the marking 'HELUKABEL F-C-PUR-5G 2.5 2015 0,6/1kV 300/500V 0010186'.

Image similar

Product type

Control lead

No. of leads

3 G

Cross section (each core)

0.50 mm²

Cable type

F-C-PURö-JZ

Outside Ø

5.90 mm

Datasheet (PDF)

Dispatches on Fri 16 Oct

7 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Set(s)

Total (1 m = € 3.45)

€ 345.00

incl. VAT

Only 7 Set(s) available

14-day return policy included

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 3 G

Content: 100 m

Cross section (each core): 0.50 mm²

Cable features: Shielded
Ozone-resistant
UV-resistant
Charpy impact tested
incl. graduation (metres)
Oil-resistant
Oil- and abrasion-resistant

Cable type: F-C-PURö-JZ

Outside Ø: 5.90 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 10

Halogen-free: No

Manufacturer part #: 21201

Factory colour: Grey

Insulation material: PUR

Insulation: PVC

Core layout: Plain copper wire, according to DIN VDE 0295, class 5, fine wire

Material (details): PVC

Max. length sold by the metre: 100 m

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Cross section: 3 G 0.50 mm²

Suited for cable carriers: No

Max. temperature range (flexible installation): +80 °C

Min. temperature range (flexible installation): -20 °C

Max. temperature range (fixed installation): +80 °C

Min. temperature range (fixed installation): -40 °C

Type: F-C-PURÖ-JZ
