Name: HELU H05VV5-F Control lead 2 x 1 mm² Grey 13119 100 m
Brand: HELU
SKU: 1972677
Availability: InStock

Electrical cable with inscription: 'HELUKABEL (DE) CHARD H05V-K 16G1.5 0 MM² 100M 300/500V 00040096 CE'. Cable is multi-core.

1/2

Image similar

Product type

Control lead

No. of leads

2 x

Cross section (each core)

1 mm²

Cable type

H05VV5-F

Outside Ø

7.50 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Fri 30 Oct

13 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Set(s)

Total (1 m = € 1.35)

€ 134.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 2 x

Content: 100 m

Cross section (each core): 1 mm²

Cable features: Oil-resistant
incl. graduation (metres)
Flexible
Flame-retardant

Cable type: H05VV5-F

Outside Ø: 7.50 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 7.5

Halogen-free: No

Manufacturer part #: 13119

Factory colour: Grey

Insulation material: PVC

Insulation: PVC

Core layout: Plain copper wire, according to DIN VDE 0295, class 5, fine wire

Material (details): PVC

Max. length sold by the metre: 100 m

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: (5 min) 2 kV

Cross section: 2 x 1 mm²

Suited for cable carriers: No

Max. temperature range (flexible installation): +70 °C

Min. temperature range (flexible installation): -5 °C

Max. temperature range (fixed installation): +70 °C

Min. temperature range (fixed installation): -40 °C

Type: H05VV5-F

Variants(All information include VAT, plus shipping costs)

Cable type

Content

Cross section (each core)

No. of leads

Outside Ø

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 0.50 mm² Grey 13007 100 m

Item no:1972559

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

100 m

0.50 mm²

12 G

12.90 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 265.00^*

1 m = € 2.65

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 0.50 mm² Grey 13007-1000 1000 m

Item no:3039113

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

1000 m

0.50 mm²

12 G

12.90 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 0.50 mm² Grey 13007-500 500 m

Item no:3041409

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

500 m

0.50 mm²

12 G

12.90 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 0.75 mm² Grey 13019 100 m

Item no:1972737

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

100 m

0.75 mm²

12 G

13.70 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 489.00^*

1 m = € 4.89

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 0.75 mm² Grey 13019-1000 1000 m

Item no:3038839

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

1000 m

0.75 mm²

12 G

13.70 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 0.75 mm² Grey 13019-500 500 m

Item no:3041250

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

500 m

0.75 mm²

12 G

13.70 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 1 mm² Grey 13031 100 m

Item no:1972615

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

100 m

1 mm²

12 G

14.60 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 645.00^*

1 m = € 6.45

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 1 mm² Grey 13031-1000 1000 m

Item no:3038793

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

1000 m

1 mm²

12 G

14.60 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 12 G 1 mm² Grey 13031-500 500 m

Item no:3041188

Unavailable

Conrad Electronic

H05VV5-F (NYSLYÖ-JZ)

500 m

1 mm²

12 G

14.60 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU H05VV5-F (NYSLYÖ-JZ) Control lead 3 G 0.50 mm² Grey 13001 100 m
