Name: HELU JZ-500 HMH-C Control lead 4 G 1 mm² Grey 11702 100 m
Brand: HELU
SKU: 1973032
Availability: InStock

Figure of a grey HELUKABEL JZ-500 cable with specifications: 0.6/1 kV, halogen-free, 7G2.5 mm². CE certification visible.

Image similar

Product type

Control lead

No. of leads

4 G

Cross section (each core)

1 mm²

Cable type

JZ-500 HMH-C

Outside Ø

7.20 mm

Datasheet (PDF)

Dispatches on Thu 15 Oct

7 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Set(s)

Total (1 m = € 3.95)

€ 395.00

incl. VAT

Only 7 Set(s) available

14-day return policy included

Report legal concerns

Technical specifications

Product type: Control lead

No. of leads: 4 G

Content: 100 m

Cross section (each core): 1 mm²

Cable features: Oil-resistant
incl. graduation (metres)
Flame-retardant
Flexible
Halogen-free
Shielded

Cable type: JZ-500 HMH-C

Outside Ø: 7.20 mm

Packaged: Yes

Wire ID code: DIN VDE 0293

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 10

Halogen-free: Yes

Manufacturer part #: 11702

Factory colour: Grey

Insulation material: Polymer

Insulation: other

Core layout: Plain copper wire, according to DIN VDE 0295, class 5, fine wire

Material (details): Halogen-free polymer TM7

Max. length sold by the metre: 100 m

Sold per metre: No

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Number-coded: Yes

Test voltage: 2000 V

Cross section: 4 G 1 mm²

Suited for cable carriers: No

Max. temperature range (flexible installation): +70 °C

Min. temperature range (flexible installation): -15 °C

Max. temperature range (fixed installation): +70 °C

Min. temperature range (fixed installation): -40 °C

Type: JZ-600 HMH

Variants(All information include VAT, plus shipping costs)

No. of leads

Content

Cable type

Cross section (each core)

Outside Ø

Cable features

HELU JZ-500 HMH Control lead 7 G 0.75 mm² Grey 11225 100 m

Item no:1972989

Unavailable

Conrad Electronic

7 G

100 m

JZ-500 HMH

0.75 mm²

7.50 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 345.00^*

1 m = € 3.45

HELU JZ-500 HMH Control lead 7 G 0.75 mm² Grey 11225-1000 1000 m

Item no:3039313

Unavailable

Conrad Electronic

7 G

1000 m

JZ-500 HMH

0.75 mm²

7.50 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU JZ-500 HMH Control lead 7 G 0.75 mm² Grey 11225-500 500 m

Item no:3041853

Unavailable

Conrad Electronic

7 G

500 m

JZ-500 HMH

0.75 mm²

7.50 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU JZ-500 HMH-C Control lead 3 G 0.50 mm² Grey 11657 100 m

Item no:1972700

Unavailable

Conrad Electronic

3 G

100 m

JZ-500 HMH-C

0.50 mm²

5.90 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 239.99^*

1 m = € 2.40

HELU JZ-500 HMH-C Control lead 3 G 0.50 mm² Grey 11657-1000 1000 m

Item no:3040256

Unavailable

Conrad Electronic

3 G

1000 m

JZ-500 HMH-C

0.50 mm²

5.90 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU JZ-500 HMH-C Control lead 3 G 0.50 mm² Grey 11657-500 500 m

Item no:3042482

Unavailable

Conrad Electronic

3 G

500 m

JZ-500 HMH-C

0.50 mm²

5.90 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU JZ-500 HMH-C Control lead 3 G 0.75 mm² Grey 11679 100 m

Item no:1972557

Unavailable

Conrad Electronic

3 G

100 m

JZ-500 HMH-C

0.75 mm²

6.30 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 219.99^*

1 m = € 2.20

HELU JZ-500 HMH-C Control lead 3 G 0.75 mm² Grey 11679-1000 1000 m

Item no:3039526

Unavailable

Conrad Electronic

3 G

1000 m

JZ-500 HMH-C

0.75 mm²

6.30 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU JZ-500 HMH-C Control lead 3 G 0.75 mm² Grey 11679-500 500 m

Item no:3042344

Unavailable

Conrad Electronic

3 G

500 m

JZ-500 HMH-C

0.75 mm²

6.30 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

HELU JZ-500 HMH-C Control lead 3 G 1 mm² Grey 11701 100 m

Item no:1972661

Unavailable

Conrad Electronic

3 G

100 m

JZ-500 HMH-C

1 mm²

6.70 mm

Oil-resistant

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 275.00^*

1 m = € 2.75

Documents & Downloads

Datasheet

Datasheet 1973032 HELU JZ-500 HMH-C Control lead 4 G 1 mm² Grey 11702 100 m

User & Safety Instructions

User & Safety Instructions 1973032 HELU JZ-500 HMH-C Control lead 4 G 1 mm² Grey 11702 100 m
