Buy IMI NORGREN Pressure switch 0880300000000000 G1/4 0.5 up to 8 bar 1 change-over 1 pc(s)

Metal switch with dimensions: Length 72 mm, Width 30 mm, Height 30 mm, Connection G1/4. Maximum 250 V, 6 A.

The circuit symbol represents a MOSFET with an integrated protective diode network, used for control and current regulation in digital circuits.

1/2

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

36 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 142.85 / piece)

€ 176.47

-19 %

€ 142.85

plus VAT.

Report legal concerns

Technical specifications

Reproducibility: ±3 %, with vacuum ±4 %
Rate of switching: 100/min
Protection class IP65
Material: Aluminium casing

Type: 0880300000000000

Operating medium: For neutral, gaseous and fluid media

Product type: Pressure switch

Min. switching pressure range: 0.5 bar

Max. switching pressure range: 8 bar

Switching pressure: 0.5 up to 8 bar

Media temperature (range): -10 up to +80 °C

Type: For Compressed air

Display: No

Operating temperature: -10 up to +80 °C

Min. operating temperature: -10 °C

Max. operating temperature: +80 °C

Manufacturer part #: 0880300000000000

Fluid connection: G1/4

Contact type: 1 change-over

Max. media temperature: +80 °C

Media temperature (min.): -10 °C
