Impulse changeover switch Flush mount Finder 26.02.8.110.4000 2 makers 110 V AC 10 A 2500 VA 1 pc(s)
Product type
Impulse changeover switch
Operating voltage
110 V AC
Contact type
2 makers
Switching voltage (max.)
250 V AC
Switching current (max.)
10 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 14.99 / piece)
€ 14.99
incl. VAT
Only 3 Piece(s) available
Technical specifications
- Product type
Impulse changeover switch
- Type
26.02.8.110.4000
- Operating voltage
110 V AC
- Min. operating voltage
88 V AC
- Max. operating voltage
121 V AC
- Operating voltage
88 - 121 V AC
- Time interval setting
100 %
- Switch-on current
200 A
- Permanent current (max.)
10 A
- Contact type
2 makers
- Contact material
Silver tin oxide
- Switching sequence step 1
OFF
- Switching sequence step 2
OFF-ON
- Switching sequence step 3
ON
- Switching voltage (max.)
250 V AC
- Switching current (max.)
10 A
- Max. switching capacity
2500 VA
- Mounting type
Flush mount
- Connection
Clamp
- Min. temperature
-40 °C
- Max. temperature
40 °C
- Width
35.2 mm
- Height
50.3 mm
- Depth
22.7 mm
- Dim
(W x H x D) 35.2 x 50.3 x 22.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 3588279 Impulse changeover switch Flush mount Finder 26.02.8.110.4000 2 makers 110 V AC 10 A 2500 VA 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3588279 Impulse changeover switch Flush mount Finder 26.02.8.110.4000 2 makers 110 V AC 10 A 2500 VA 1 pc(s)
