Impulse changeover switch Flush mount Finder 26.03.8.012.4000 1 maker, 1 breaker 12 V AC 10 2500 VA 1 pc(s)
EAN:
Part number:
Item no:
Product type
Impulse changeover switch
Operating voltage
12 V AC
Contact type
1 maker
1 breaker
Switching voltage (max.)
250 V AC
Switching current (max.)
10
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 11.76
3
6% = € 0.65
€ 11.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 11.76 / piece)
€ 11.76
plus VAT.
Technical specifications
- Product type
Impulse changeover switch
- Type
26.03.8.012.4000
- Operating voltage
12 V AC
- Min. operating voltage
9.6 V AC
- Max. operating voltage
13.2 V AC
- Operating voltage
9.6 - 13.2 V AC
- Time interval setting
100 %
- Switch-on current
200 A
- Permanent current (max.)
10 A
- Contact type
1 maker
1 breaker
- Contact material
Silver tin oxide
- Switching sequence step 1
OFF
- Switching sequence step 2
ON-ON
- Switching sequence step 3
OFF
- Switching voltage (max.)
250 V AC
- Switching current (max.)
10
- Max. switching capacity
2500 VA
- Mounting type
Flush mount
- Connection
Clamp
- Min. temperature
-40 °C
- Max. temperature
40 °C
- Width
35.2 mm
- Height
50.3 mm
- Depth
22.7 mm
- Dim
(W x H x D) 35.2 x 50.3 x 22.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3588281 Impulse changeover switch Flush mount Finder 26.03.8.012.4000 1 maker, 1 breaker 12 V AC 10 2500 VA 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3588281 Impulse changeover switch Flush mount Finder 26.03.8.012.4000 1 maker, 1 breaker 12 V AC 10 2500 VA 1 pc(s)
