IVT Switcher US-16 3600 VA 400034 160 mm x 145 mm x 77 mm Suitable for (inverters):Universal
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 84.03 / piece)
€ 84.03
plus VAT.
Highlights & Details
Switching station US-16
- Suitable for sine wave inverter up to 3600 VA
- Precise switching thanks to high-quality relay
- Freely selectable mains priority circuit
- This text is machine translated.
Technical specifications
- Protection class IP55
- Screw terminal connectors
- Switching time 0.5 s
- Input current Max. 16 A
- Product type
Switcher
3600 VA
- Suitable for
Universal
- Type
US-16
- Width
160 mm
- Height
145 mm
- Depth
77 mm
- Weight
450 g
- Output voltage
230 V AC
- Input voltage
230 V AC
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1712786 IVT Switcher US-16 3600 VA 400034 160 mm x 145 mm x 77 mm Suitable for (inverters):Universal
User & Safety Instructions
User & Safety Instructions 1712786 IVT Switcher US-16 3600 VA 400034 160 mm x 145 mm x 77 mm Suitable for (inverters):Universal
Description
Fused Power thanks to precise switching.
The switching station allows you free of interference 230 V/AC consumers via two different voltage sources, for example, via a converter and the public 230V power supply.
With the priority circuit, you specify the voltage source is preferred to be used, this voltage source, the switching station switches automatically to the replacement power source. Run your devices during a power outage or exhausted battery.
The high-quality relays provide for a precise switching threshold. This is your inverter particularly well against rear feed of external voltage protected.
Use recommendation: suitable for solar island systems, car, service and commercial vehicles, mobile homes, caravans, motor and sailing boats, and many more.
This text is machine translated.
The switching station allows you free of interference 230 V/AC consumers via two different voltage sources, for example, via a converter and the public 230V power supply.
With the priority circuit, you specify the voltage source is preferred to be used, this voltage source, the switching station switches automatically to the replacement power source. Run your devices during a power outage or exhausted battery.
The high-quality relays provide for a precise switching threshold. This is your inverter particularly well against rear feed of external voltage protected.
Use recommendation: suitable for solar island systems, car, service and commercial vehicles, mobile homes, caravans, motor and sailing boats, and many more.
This text is machine translated.
Features
- Suitable for sine wave inverter up to 3600 VA
- Microprocessor-controlled
- Circuit breaker
- Overload protection
- Protection against back feed
- Priority circuit
- Freely selectable mains priority circuit
- Reliably switches between two 230 V/AC power sources to
- Precise switching thanks to high-quality relay
- Dust and splash-water protected
- Additional fuse
Scope of delivery
- Transition station
- User manual.
