Name: LAPP 12345/50 Connection cable ÖLFLEX® 500 P 2 x 1 mm² Orange 50 m
Brand: LAPP
SKU: 1028085
Availability: SoldOut

LAPP 12345/50 Connection cable ÖLFLEX® 500 P 2 x 1 mm² Orange 50 m-0

Orange cable with the inscription 'Lapp Kabel Ölflex Classic 100 Y'. Cable sheathing shows several coloured wires at one end.

1/2

Product type

Connection cable

Cable type

ÖLFLEX® 500 P

No. of leads

2 x

Cross section (each core)

1 mm²

Content

50 m

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (1 m = € 3.90)

€ 194.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

ÖLFLEX® 500 P Workshop wire

Technical specifications

Product type: Connection cable

Cable type: ÖLFLEX® 500 P

No. of leads: 2 x

Cross section (each core): 1 mm²

Cross section: 2 x 1 mm²

Cable features: Halogen-free
Cold-resistant
Oil-resistant
PUR coating
highly flexible

Factory colour: Orange

Outside Ø: 6.8 mm

Content: 50 m

Nominal voltage: 500 V

Nominal voltage U0: 300 V

Test voltage: 3000 V

Bend radius (no. of ODs for fixed installation): 4

Bend radius (no. of ODs for flexible installation): 10

Core layout: Extra-finely stranded according to VDE 0295 class 6/IEC 228 class 66

Packaged: Yes

Sold per metre: No

Halogen-free: Yes

Shielded: No

Manufacturer part #: 12345/50

Insulation material: Polyurethane

Min. temperature range (flexible installation): -40 °C

Max. temperature range (flexible installation): +80 °C

Min. temperature range (fixed installation): -50 °C

Max. temperature range (fixed installation): +80 °C

Certification marks: According to VDE 0250

Wire ID code: to VDE 0293 or VDE 0293-308

Type: ÖLFLEX® 500 P

Material (details): Outer cover/jacket: Polyurethane

Nominal voltage (details): 300/500 V

Bend radius: Minimum bend radius for flexible application: 15 x external dia. · when fixed: 4 x external dia.

Temperature range: -40 - +80 °C, applications with movement: · Firmly laid: -50 - +80 °C

Documents & Downloads

Datasheet

Datasheet 1028085 LAPP 12345/50 Connection cable ÖLFLEX® 500 P 2 x 1 mm² Orange 50 m

Description

This highly flexible, (even at low temperatures), cut and abrasion resistant PUR workshop cable is well suited for the high demands of power handtools. The excellent attributes of the cable include its high chemical, petrol and mineral oil resistance, long service life, abrasion resistance, microbe and water resistant, and that fact that it is halogen-free.
