Name: LAPP 35161/1 Data transfer cable UNITRONIC® LiYY (TP) 3 x 2 x 0.25 mm² Grey Sold per metre
Brand: LAPP
SKU: 602790
Availability: InStock

A cable with the marking 'LAPP KABEL, STUTTGART UNITRONIC LiYY (TP)' is half stripped and reveals colourful, twisted inner conductors.

Image similar

Product type

Data transfer cable

No. of leads

6 x

Cross section (each core)

0.25 mm²

Cable features

Flame-retardant

Cable type

UNITRONIC® LiYY (TP)

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

160 meter

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

meter

Total (€ 1.79 / piece)

€ 1.79

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

UNITRONIC® LiYY (TP) Dataline

Twisted Pair
DIN-Colour code

Technical specifications

Product type: Data transfer cable

Cable type: UNITRONIC® LiYY (TP)

No. of leads: 6 x

Cross section (each core): 0.25 mm²

Twisted pair cabling (part 1): Yes (1)

Cross section: 3 x 2 x 0.25 mm²

Cable features: Flame-retardant

Outside Ø: 6.20 mm

Factory colour: Grey

Content: Sold per metre

Nominal voltage (details): 250 V (not for heavy current applications)

Bend radius (no. of ODs for fixed installation): 5

Bend radius (no. of ODs for flexible installation): 15

Packaged: No

Sold per metre: Yes

Halogen-free: No

Shielded: No

Manufacturer part #: 35161/1

Insulation material: PVC

Wire ID code: DIN 47100

Core layout: Braid, fine strands

Min. temperature range (flexible installation): -5 °C

Max. temperature range (flexible installation): +70 °C

Min. temperature range (fixed installation): -40 °C

Max. temperature range (fixed installation): +80 °C

Certification marks: In Following an VDE 0814 (DIN 47414) and VDE 0812

Max. length sold by the metre: 100 m

Type: UNITRONIC® LiYY (TP)

Cable type: LiYY TP

Type: UNiTRONiC® LiYY (TP) 3x2x0.25

Cross section: 3 x 2 x 0.25 mm²

Bend radius: For flexible Use: 10 x Outer-Ø

Temperature range: Fixed installation: -30 - +80 °C

Variants(All information include VAT, plus shipping costs)

No. of leads

Content

Cross section (each core)

LAPP 35101/1 Data transfer cable UNITRONIC® LiYY (TP) 2 x 2 x 0.14 mm² Grey Sold per metre

Item no:600797

Fast track dispatch on Wed 14 Oct

318 meterConrad Electronic

4 x

Sold per metre

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.29^*

LAPP 35102/1 Data transfer cable UNITRONIC® LiYY (TP) 3 x 2 x 0.14 mm² Grey Sold per metre

Item no:600810

Fast track dispatch on Wed 14 Oct

375 meterConrad Electronic

6 x

Sold per metre

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.29^*

LAPP 35103/1 Data transfer cable UNITRONIC® LiYY (TP) 4 x 2 x 0.14 mm² Grey Sold per metre

Item no:600824

Fast track dispatch on Wed 14 Oct

360 meterConrad Electronic

8 x

Sold per metre

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.79^*

LAPP 35101/100 Data transfer cable UNITRONIC® LiYY (TP) 2 x 2 x 0.14 mm² Grey 100 m

Item no:1046334

Unavailable

Conrad Electronic

4 x

100 m

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

LAPP 35101/1000 Data transfer cable UNITRONIC® LiYY (TP) 2 x 2 x 0.14 mm² Grey 1000 m

Item no:1046335

Unavailable

Conrad Electronic

4 x

1000 m

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

LAPP 35102/100 Data transfer cable UNITRONIC® LiYY (TP) 3 x 2 x 0.14 mm² Grey 100 m

Item no:1046340

Unavailable

Conrad Electronic

6 x

100 m

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

LAPP 35102/1000 Data transfer cable UNITRONIC® LiYY (TP) 3 x 2 x 0.14 mm² Grey 1000 m

Item no:1046341

Unavailable

Conrad Electronic

6 x

1000 m

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

LAPP 35103/100 Data transfer cable UNITRONIC® LiYY (TP) 4 x 2 x 0.14 mm² Grey 100 m

Item no:1046346

Unavailable

Conrad Electronic

8 x

100 m

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

LAPP 35103/1000 Data transfer cable UNITRONIC® LiYY (TP) 4 x 2 x 0.14 mm² Grey 1000 m

Item no:1046347

Unavailable

Conrad Electronic

8 x

1000 m

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

LAPP 35104/100 Data transfer cable UNITRONIC® LiYY (TP) 5 x 2 x 0.14 mm² Grey 100 m

Item no:1046352

Unavailable

Conrad Electronic

10 x

100 m

0.14 mm²

Piece(s)

Minimum order quantity: 1

Multiple: 1

Documents & Downloads

Datasheet

Datasheet 602790 LAPP 35161/1 Data transfer cable UNITRONIC® LiYY (TP) 3 x 2 x 0.25 mm² Grey Sold per metre

User & Safety Instructions

User & Safety Instructions 602790 LAPP 35161/1 Data transfer cable UNITRONIC® LiYY (TP) 3 x 2 x 0.25 mm² Grey Sold per metre

Information

Information 602790 LAPP 35161/1 Data transfer cable UNITRONIC® LiYY (TP) 3 x 2 x 0.25 mm² Grey Sold per metre

Description

This Data line is used as a Control and Signal line of Electronics for computer equipment, Electronic and Control equipment, office machinery, Scales, etc. The core insulation of special PVC provides small Ø and the PVC Outer jacket makes this Cable durable and flexible.
