Technical drawing of a component with measurements in millimetres; shows dimensions and positioning of the components.

1/2

Image similar

Product type

Pushbutton

Lighting type

None

Switch position

1 x On/(On)

Contact type

1 breaker

1 maker

Connection

Type C CEE 7/16 plug 6.3 mm

Datasheet (PDF)

Marquardt

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 12.10 / piece)

€ 12.10

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Marquardt 1115.0101 1115.0101 Pushbutton 380 V AC 16 A 1 x On/(On) momentary (L x W x H) 30 x 13 x 23.2 mm IP40 1 pc(s)

Technical specifications

Product type: Pushbutton

Switch/button features: Protruding

Casing/button colour: Black

Functions: momentary

Lighting type: None

Switch position: 1 x On/(On)

Contact type: 1 breaker
1 maker

Connection: Type C CEE 7/16 plug 6.3 mm

Switching voltage: 380 V AC

Switching current (max.): 16 A

Min. temperature: -40 °C

Max. temperature: +85 °C

Length: 30 mm

Width: 13 mm

Height: 23.2 mm

: IP40

Actuating force: 6.5 N

Content: 1 pc(s)

Dim: (L x W x H) 30 x 13 x 23.2 mm

Type: 1115.0101

Switching voltage: 380 V AC

Switching current: 16 A

Type: 1115.0101

Actuating force: 6,5 N

Connection: 6.3 mm flat plug

Temperature range: -40 - +85 °C

Documents & Downloads

Datasheet

Datasheet 702682 Marquardt 1115.0101 1115.0101 Pushbutton 380 V AC 16 A 1 x On/(On) momentary (L x W x H) 30 x 13 x 23.2 mm IP40 1 pc(s)

User & Safety Instructions

User & Safety Instructions 702682 Marquardt 1115.0101 1115.0101 Pushbutton 380 V AC 16 A 1 x On/(On) momentary (L x W x H) 30 x 13 x 23.2 mm IP40 1 pc(s)

Information

Information 702682 Marquardt 1115.0101 1115.0101 Pushbutton 380 V AC 16 A 1 x On/(On) momentary (L x W x H) 30 x 13 x 23.2 mm IP40 1 pc(s)

Hints

Re switch position: content in parentheses describes the n/o and n/c contact constellation

Description

Hints

Re switch position: content in parentheses describes the n/o and n/c contact constellation
