MEAN WELL DPU01N-05 DC/DC converter (module) 100 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 6.49 / piece)
€ 6.49
incl. VAT
14-day return policy included
Highlights & Details
MEANWELL DC/DC converter modules series DPU01 SIP/SIL 6 Case Dual Output Input voltage ratio: 1:1 Power: 1 W Unregulated
- In the SIP/SIL6-casing
- For direct PCB mounting
- Input/output insulation 1500 V
- According to EN 55032 Class A transmitted without additional components
- Efficiency up to 83%
- Circuit breaker
- Low Cost
Technical specifications
- Product type
DC/DC converter (module)
- Type
DPU01N-05
- Min. input voltage
21.6 V DC
- Input voltage (max.)
26.4 V DC
- No. of outputs
2 x
- Max. output current
100 mA
- Output current (max.) - rounded
100 mA
- Efficiency (max.)
80 %
1 W
- Insulation voltage
1500 V DC
- Connection
Pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+90 °C
- Dim
(L x W x H) 19.5 x 7.2 x 10.2 mm
- Height
10.2 mm
- Length
19.5 mm
- Width
7.2 mm
- Output voltage (max.)
5 V DC
-5 V DC
- Weight
2.7 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2143424 MEAN WELL DPU01N-05 DC/DC converter (module) 100 mA 1 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2143424 MEAN WELL DPU01N-05 DC/DC converter (module) 100 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 2143424 MEAN WELL DPU01N-05 DC/DC converter (module) 100 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Description
With the launch of eight new series of unsettled (SPU 01, DPU01) and regulated DC/DC converters (02, 02, 03, 03, SPBW DPBW SPBW DPAN06 and DPBW06) in the area of up to 10 W now offers mean corrugated a complete range of power supply solutions. These eight series are designed so that a standard SIP Pin assignment. In addition to a wide input range (2:1 and 4:1) and a wide operating temperature range from -40 up to +90 °C, all with 1500 V DC I/O insulation. Suitable applications include IoT, electronics, telecommunications, networking, industrial control and distributed power architecture.
This text is machine translated.
This text is machine translated.
Features
- In the SIP/SIL6-casing
- For direct PCB mounting
- Input/output insulation 1500 V
- Efficiency up to 83%
- Circuit breaker
