Name: Metz Connect 11056170 PSU 24 V DC 700 mA 16 W Content 1 pc(s)
Brand: Metz Connect
SKU: 3164637
Availability: BackOrder

Industrial switch for power supplies, METZ CONNECT, Model NG4-F, with 24V connections and diagram showing connection options.

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Mon 9 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 114.99 / piece)

€ 114.99

incl. VAT

14-day return policy included

Report legal concerns

Alternative article by TRU COMPONENTS

TRU COMPONENTS TC-10580792 Rail mounted PSU (DIN) 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Fast track dispatch on Thu 29 Oct

€ 31.99

incl. VAT plus

Technical specifications

Input frequency range 47 ~ 63Hz
Power resistance 4000 V/AC (input/output)
Connection terminal 4-pin
Colour: grey
Material housing: Polyamide 6.6 V0

Product type: PSU

Min. input voltage: 110 V AC

Inputs: 1

Input voltage: 110 - 240 V AC

Input voltage (max.): 240 V AC

Max. output current: 700 mA

Output current (max.) - rounded: 700 mA

: 16 W

Output type (power supply units): Fixed voltage

Output voltage (nominal): 24 V DC

Connection: Screw terminal

Dim: (L x W x H) 60 x 50 x 69.30 mm

Weight: 108 g

Output voltage (max.): 24 V DC

Output voltage (min.): 24 V DC

Operating temperature (max.): +55 °C

Operating temperature (min.): -10 °C

Manufacturer part #: 11056170

Content: 1 pc(s)

Width: 50 mm

Height: 69.30 mm

Length: 60 mm

: IP40
Protection class II

Type: NG4-F

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 3164637 Metz Connect 11056170 PSU 24 V DC 700 mA 16 W Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3164637 Metz Connect 11056170 PSU 24 V DC 700 mA 16 W Content 1 pc(s)

Description

The NG4-F power supply unit supplies a regulated DC voltage of 24 V DC / 16 W for the supply of devices in the product family I/O components. The secondary voltage can only be tapped on the right side of the device front through a pluggable terminal as well as through the spring force clamps. Bus communication can be picked up on both sides of the device front with plug-in terminals. Parallel operation of several power supply units is not permitted. Suitable for decentralized mounting on support rail TH35 as per IEC 60715 in electric distributors. Connection with spring clamps (Push-In).

This text is machine translated.
