Microchip Technology MCP3008-I/P Data acquisition IC - AD converter (ADC) External PDIP 16

A black IC chip with 14 metal pins is shown; commonly used in electronic devices.
Image similar
Product type
Data acquisition IC - AD converter (ADC)
Enclosure
PDIP 16
Interfaces
SPI™
Configuration
MUX-S/H-ADC
Mounting type
Through-hole
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
60 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 7.49 / piece)
€ 7.49
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Type

MCP3008-I/P

Product type

Data acquisition IC - AD converter (ADC)

Enclosure

PDIP 16

Manufacturer

Microchip Technology

Manuf. code

MCP

Input type

Pseudo-symmetric

Single-ended

Interfaces

SPI™

Configuration

MUX-S/H-ADC

No. of ADCs

1

Architecture (semiconductor)

SAR

Type of reference

External

Supply voltage (digital) (min.)

2.7 V

Supply voltage (digital) (max.)

5.5 V

Supply voltage (analogue) (min.)

2.7 V

Supply voltage (analogue) (max.)

5.5 V

ADC S/H ratio

1:1

No. of inputs

4 x

8 x

No. of bits

10 Bit

Sampling rate

200 kSa/s

Operating temperature (min.)

-40 °C

Operating temperature (max.)

+85 °C

Mounting type

Through-hole

Documents & Downloads

Datasheet

Datasheet 651456 Microchip Technology MCP3008-I/P Data acquisition IC - AD converter (ADC) External PDIP 16

User & Safety Instructions

User & Safety Instructions 651456 Microchip Technology MCP3008-I/P Data acquisition IC - AD converter (ADC) External PDIP 16

Description

Integrated circuits from leading manufacturers. Please read our extensive documentation, which is free to download.
