Name: Molex Built-in SIL socket (standard) Total number of pins 8 Contact spacing: 4.2 mm 1724470208 1 pc(s) Tray
Brand: Molex
SKU: 2447465
Price: 2.05 EUR
Availability: SoldOut

'Black, rectangular plug with eight square openings and six metallic pins on the underside, isolated on white.'

Product type

Built-in SIL socket (standard)

No. of rows

4.2 mm

Total number of pins

Packaging type

Tray

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 2.05 / piece)

€ 2.29

-10 %

€ 2.05

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

MINI FIT

Content: 1 pc(s)
No. of rows: 2
Total number of pins: 8

Our service for you

Technical specifications

Please review product datasheet for further information.

Packaging type: Tray

Product type: Built-in SIL socket (standard)

No. of rows: 2

Features: + locking mechanism
encodable

CS: 4.2 mm

Total number of pins: 8

Nominal current: 9 A

Nominal current - rounded value: 9 A

Content: 1 pc(s)

Connection: Soldering

Case material: Nylon (NL)

Manufacturer part #: 1724470208

Factory colour: Black

Contact material: Brass

Connector contact surface: Tin

Nominal voltage: 600 V DC/AC

RoHS-compliant: Yes

Connector orientation: Perpendicular (to the PCB)

Max. temperature: +105 °C

Min. temperature: -40 °C

Type: Molex MOL Power & Signal Sol.

Engineering Part No: 172447-0208

Engineering Series Name: MiniFit Jr Vert Hdr

Engineering Series No: 172447

Documents & Downloads

Datasheet

Datasheet 2447465 Molex Built-in SIL socket (standard) Total number of pins 8 Contact spacing: 4.2 mm 1724470208 1 pc(s) Tray

User & Safety Instructions

User & Safety Instructions 2447465 Molex Built-in SIL socket (standard) Total number of pins 8 Contact spacing: 4.2 mm 1724470208 1 pc(s) Tray

Circuit diagramm

Circuit diagramm 2447465 Molex Built-in SIL socket (standard) Total number of pins 8 Contact spacing: 4.2 mm 1724470208 1 pc(s) Tray

Description

Mini-Fit Jr. Header, Dual Row, Vertical, without Snap-in Plastic Peg PCB Lock, 8 Circuits, PA Polyamide Nylon 6/6 94V-2, Tin (Sn) Plating, Glow-Wire Capable
