Name: Molex Pin strip (standard) No. of rows: 1 Pins per row: 10 901200770 1 pc(s) Tray
Brand: Molex
SKU: 2450563
Availability: InStock

Two pin header connectors with long gold-plated contacts and black plastic bases, used for establishing electrical connections on a circuit board.

Illustration of a rectangular connector with seven pins in a single row.

1/2

Image similar

Packaging type

Tray

Product type

Pin strip (standard)

No. of rows

Total number of pins

2.54 mm

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

788 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 70

Multiple: 1

Total (€ 2.05 / piece)

€ 2.05

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

C-GRID 111

Content 1 pc(s)
No. of rows 1
Pins per row 10

Technical specifications

Breakaway: YesRecommended PCB thickness: 1.6 mmProcess temperature max. 260 °C.

Packaging type: Tray

Product type: Pin strip (standard)

No. of rows: 1

Pins per row: 10

Total number of pins: 10

CS: 2.54 mm

Connection: Soldering

Factory colour: Black

Nominal voltage: 350 V DC/AC

Nominal current: 3 A

Nominal current - rounded value: 3 A

Contact surface: Gold (Au)

Contact material: Brass

Case material: Polyester

Separable: Yes

Connector orientation: Perpendicular (to the PCB)

Manufacturer part #: 901200770

Content: 1 pc(s)

RoHS-compliant: Yes

Max. temperature: +125 °C

Min. temperature: -55 °C

Type: Molex MOL Power & Signal Sol.

Engineering Part No: 90120-0770

Engineering Series Name: SR HDR VERT

Engineering Series No: 90120

Leading contact (PE): No

Connector contact surface: Gold

Board contact surface: Ni

Mating cycles: 200

Connector coating thickness: 0.381 µm

Range of uses: Signal, cable to PCB

Pin length: 2.9 mm

UKCA: yes
