Panasonic Reflective light barrier PM-R65-P PM-R65-P R Light-ON, Dark-ON 5 - 24 V DC 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 20.16
3
5% = € 1.00
€ 19.16
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 20.16 / piece)
€
Only 7 Piece(s) available
Highlights & Details
Fork light barrier, Series PM (65)
- Fork width: 6mm
- Short response time of 20 μs bright-on
- Response time 80 μs dark-on
- Foreign Light independent
- Reverse polarity protection
Technical specifications
- Type
PM-R65-P
- Model
R
- Functions
Light-ON
Dark-ON
- Min. operating voltage
5 V DC
- Max. operating voltage
24 V DC
- Operating voltage
5 - 24 V DC
- Outputs
PNP
- Connector
Plug (4-pin)
- Enclosure material
PBT
- Transmitter type
LED IR
- Wavelength
855 nm
IP40
- Min. temperature
-25 °C
- Max. temperature
+55 °C
- Length
13.4 mm
- Width
13.5 mm
- Height
22.4 mm
- Dim
(L x W x H) 13.4 x 13.5 x 22.4 mm
- Product type
Reflective light barrier
Documents & Downloads
Datasheet
Datasheet 1547428 Panasonic Reflective light barrier PM-R65-P PM-R65-P R Light-ON, Dark-ON 5 - 24 V DC 1 pc(s)
Description
Fork light beam in very small size. Two transistor outputs bright-on and dark-on. LED display of switching status Jet markings for easy adjustment. Insensitive to vibrations and shocks.
Applications: contactless switch, object detection (e.g. coins), position detection, scanning (e.g. register marks), Coding disc query, speed and speed detection, band crack testing.
This text is machine translated.
Applications: contactless switch, object detection (e.g. coins), position detection, scanning (e.g. register marks), Coding disc query, speed and speed detection, band crack testing.
This text is machine translated.
Hints
For more information on this PM-R65-P, please refer to its datasheet under 'downloadable documents'
