Name: Phaesun Sun-Peak SPR 80 Monocrystalline solar panel 80 Wp 12 V
Brand: Phaesun
SKU: 2369274
Availability: BackOrder

Highlights & Details

Solar module Sun-Peak SPR 80

Photovoltaic Module with back contact silicon solar cells
High degree of efficiency
For 12 VDC to 48VDC batteries in off-grid systems

Technical specifications

Standard4 connector
Cable cross section 4 mm².
Protection class IP65
Temperature range -40 to +85 °C

Product type: Monocrystalline solar panel

: 80 Wp

Nominal voltage: 12 V

Dim: (L x W x H) 725 x 535 x 35 mm

Efficiency: 20.6 %

Connector: MC-PV-4

Weight: 4.2 kg

Cable length: 0.90 m

Short-circuit current: 4660 mA

Open circuit voltage (OCV): 22.3 V

Nominal current: 4310 mA

Width: 535 mm

Height: 35 mm

Length: 725 mm

Voltage (max.): 18.6 V

No. of cells: 64

Documents & Downloads

Datasheet

Datasheet 2369274 Phaesun Sun-Peak SPR 80 Monocrystalline solar panel 80 Wp 12 V

User & Safety Instructions

User & Safety Instructions 2369274 Phaesun Sun-Peak SPR 80 Monocrystalline solar panel 80 Wp 12 V

Description

The Sun Peak SPR solar module has back contact silicon solar cells with a unique structure, up to 20% higher efficiency. Ideal for power remote applications.

This text is machine translated.

Features

Photovoltaic Module with back contact silicon solar cells
High degree of efficiency
For 12 V to 48 V batteries in off-grid systems
Manufactured to ISO 9001 certified procedures
High reliability thanks to high-quality materials
Reduced weight
Sturdy aluminum frame
Tempered glass
Wtterungsbestandig

Scope of delivery

Solar module
Connection cable
Connector
User manual.

Description

The Sun Peak SPR solar module has back contact silicon solar cells with a unique structure, up to 20% higher efficiency. Ideal for power remote applications.

This text is machine translated.
