Green electrical connector with five terminal blocks and metal pins at the bottom, suitable for PCB mounting.

Green electrical connector with five terminal blocks and metal pins at the bottom, suitable for PCB mounting.

Image similar

Product type

Screw terminal

CS

5.08 mm

Pins per row

3

Number of pins

3

Connection

Screw terminal

Print

Datasheet (PDF)

Phoenix Contact

Dispatches on Tue 20 Oct

59 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 100 pc(s))

Set(s)

Total (€ 1.45 / piece)

€ 144.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block SMKDS 3/ 3-5,08

Content 100 pc(s)

Technical specifications

Type: SMKDS 3/ 3-5,08

Product type: Screw terminal

Features: + extractor sleeve

CS: 5.08 mm

Pins per row: 3

Number of pins: 3

Series: SMKDS

Stripping length (max.): 8.00 mm

Connection: Screw terminal
Print

Nominal current: 24 A

Cross section (flexible) (min.): 0.20 mm²

Nominal current - rounded value: 24 A

Cross section (inflexible) (min.): 0.20 mm²

Cross section (flexible) (max.): 2.50 mm²

Cross section (inflexible) (max.): 4.00 mm²

AWG (min.): 24

Connector orientation: At an angle (to the PCB)

AWG max.: 12

Contact material: Tin plated

Factory colour: Green

Actuation direction: At an angle (to the PCB)

Manufacturer part #: 1713736

Industrial packaging: Yes

Content: 100 pc(s)

Nominal voltage: 400 V

Height: 18.00 mm

Length: 16.00 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 788256 Phoenix Contact 1713736 Screw terminal 2.50 mm² Number of pins 3 Green 100 pc(s)

User & Safety Instructions

User & Safety Instructions 788256 Phoenix Contact 1713736 Screw terminal 2.50 mm² Number of pins 3 Green 100 pc(s)

Description

PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, Pitch: 5.08 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 35 °, Color: green, The article can be aligned to create different nos. of positions!

Description

PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, Pitch: 5.08 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 35 °, Color: green, The article can be aligned to create different nos. of positions!
