Green connector with eight screw terminals, suitable for printed circuit board mounting, shows the connected technology in detail.

Green connector with eight screw terminals, suitable for printed circuit board mounting, shows the connected technology in detail.

Image similar

Product type

Screw terminal

CS

3.50 mm

Pins per row

3

Number of pins

3

Connection

Screw terminal

Print

Datasheet (PDF)

Phoenix Contact

Dispatches on Tue 20 Oct

37 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 250 pc(s))

Set(s)

Total (€ 0.72 / piece)

€ 179.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block PT 1,5/ 3-3,5-V

PT 1.5/ 3-3.5-V
Industrial packaging with 250 pieces

Technical specifications

Type: PT 1,5/ 3-3,5-V

Product type: Screw terminal

Features: + wire protector

CS: 3.50 mm

Pins per row: 3

Number of pins: 3

Series: PT

Stripping length (max.): 5.00 mm

Connection: Screw terminal
Print

Nominal current: 17.5 A

Cross section (flexible) (min.): 0.20 mm²

Nominal current - rounded value: 17.5 A

Cross section (inflexible) (min.): 0.14 mm²

Cross section (flexible) (max.): 1.50 mm²

Cross section (inflexible) (max.): 1.50 mm²

AWG (min.): 26

Connector orientation: Perpendicular (to the PCB)

AWG max.: 16

Contact material: Tin plated

Factory colour: Green

Wire protection: Yes

Actuation direction: Parallel (to the PCB)

Manufacturer part #: 1984772

Industrial packaging: Yes

Content: 250 pc(s)

Nominal voltage: 200 V

Width: 12.10 mm

Height: 10.50 mm

Length: 9.20 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 566633 Phoenix Contact 1984772 Screw terminal 1.50 mm² Number of pins 3 Green 250 pc(s)

User & Safety Instructions

User & Safety Instructions 566633 Phoenix Contact 1984772 Screw terminal 1.50 mm² Number of pins 3 Green 250 pc(s)

Description

PCB terminal block, Nominal current: 17.5 A, Nom. voltage: 200 V, Pitch: 3.5 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 90 °, Color: green

Description

PCB terminal block, Nominal current: 17.5 A, Nom. voltage: 200 V, Pitch: 3.5 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 90 °, Color: green
