Green multi-pole connector with eight screw terminals, for electrical wiring of circuits.

Green multi-pole connector with eight screw terminals, for electrical wiring of circuits.

Image similar

Product type

Screw terminal

CS

5.00 mm

Pins per row

4

Number of pins

4

Connection

Screw terminal

Print

Datasheet (PDF)

Phoenix Contact

Dispatches on Mon, 15 Feb 2027

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 250 pc(s))

Set(s)

Total (€ 1.06 / piece)

€ 265.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block PT 2,5/ 4-5,0-V

PT 2.5/ 4-5.0-V
Industrial packaging with 250 pieces

Technical specifications

Type: PT 2,5/ 4-5,0-V

Product type: Screw terminal

Features: + wire protector

CS: 5.00 mm

Pins per row: 4

Number of pins: 4

Series: PT

Stripping length (max.): 6.50 mm

Connection: Screw terminal
Print

Nominal current: 32 A

Cross section (flexible) (min.): 0.50 mm²

Nominal current - rounded value: 32 A

Cross section (inflexible) (min.): 0.50 mm²

Cross section (flexible) (max.): 4.00 mm²

Cross section (inflexible) (max.): 4.00 mm²

AWG (min.): 20

Connector orientation: Perpendicular (to the PCB)

AWG max.: 10

Contact material: Tin plated

Factory colour: Green

Actuation direction: Parallel (to the PCB)

Manufacturer part #: 1987740

Industrial packaging: Yes

Content: 250 pc(s)

Nominal voltage: 400 V

Width: 20.00 mm

Height: 13.50 mm

Length: 13.10 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 569899 Phoenix Contact 1987740 Screw terminal 4.00 mm² Number of pins 4 Green 250 pc(s)

User & Safety Instructions

User & Safety Instructions 569899 Phoenix Contact 1987740 Screw terminal 4.00 mm² Number of pins 4 Green 250 pc(s)

Description

PCB terminal block, Nominal current: 32 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 4, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 90 °, Color: green

Description

PCB terminal block, Nominal current: 32 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 4, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 90 °, Color: green
