Phoenix Contact 3210538 PT 2,5-PE/L/N Push-in Three-level Terminal PIT Grey
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Triple port PG terminal
Connection
Quick-connect
Cross section (flexible) (max.)
2.5 mm²
Cross section (inflexible) (max.)
4 mm²
Datasheet (PDF)
Number
Total (€ 6.49 / piece)
€ 6.49
incl. VAT
14-day return policy included
Technical specifications
- Packaging type
Piece
- Product type
Triple port PG terminal
- Connection
Quick-connect
- Configuration
Terre
- Cross section (flexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
2.5 mm²
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (inflexible) (max.)
4 mm²
- AWG (min.)
26
- AWG max.
12
- Clamp width
5.2 mm
- No. of rows
3
- Pins per row
2
- Number of pins
6
- Factory colour
Grey
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Nominal voltage
500 V
- Min. stripping length
8 mm
- Stripping length (max.)
10 mm
- Manufacturer part #
3210538
- Content
1 pc(s)
- Industrial packaging
No
- Type
PT 2,5-PE/L/N
- Dim
(L x W x H) 102 x 5.2 x 58 mm
- Width
5.2 mm
- Height
58 mm
- Length
102 mm
- Weight
0.02 g
- Flammability rating
V0
- Connector colour
Grey
- Insulation material
PA
- Insulation
PA
- Nominal current (details)
26 A
- Connection
-
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 733153 Phoenix Contact 3210538 PT 2,5-PE/L/N Push-in Three-level Terminal PIT Grey
User & Safety Instructions
User & Safety Instructions 733153 Phoenix Contact 3210538 PT 2,5-PE/L/N Push-in Three-level Terminal PIT Grey
Description
The three-level connection terminals PIT have three passage-levels in 5 mm slim terminal casing. They offer a high wiring density especially in cramped switching stations.
