Phoenix Contact Pin housing PCB MSTBV Total number of pins 9 Contact spacing: 5 mm 1776951 100 pc(s)

Green connector with 14 pins, suitable for electronic or electrical applications.
Image similar
Product type
Pin housing PCB
Connector type
Plug, horizontal mount
No. of rows
1
Series
MSTBV
CS
5 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 6 Nov
3 Set(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 100 pc(s))
Total (€ 2.95 / piece)
€ 295.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
Only 3 Set(s) available
14-day return policy included
Report legal concerns

Highlights & Details

Base strip MSTBV 2,5/ 9-GF

  • Content: 100 pc(s)
  • No. of rows: 1
  • Total number of pins: 9

Technical specifications

Product type

Pin housing PCB

Connector type

Plug, horizontal mount

No. of rows

1

Connector system

wire-to-board

Series

MSTBV

Features

closed

encodable

+ screw lock

CS

5 mm

Pins per row

9

Total number of pins

9

Width

55.00 mm

Nominal current

12 A

Nominal current - rounded value

12 A

Content

100 pc(s)

Dim

(L x W x H) 8.60 x 55.00 x 15.90 mm

Connection

Print

Manufacturer part #

1776951

Factory colour

Green

Industrial packaging

Yes

Contact material

Tin plated

Nominal voltage

320 V

Height

15.90 mm

Length

8.60 mm

Connector orientation

Perpendicular (to the PCB)

Type

MSTBV 2,5/ 9-GF

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 566767 Phoenix Contact Pin housing PCB MSTBV Total number of pins 9 Contact spacing: 5 mm 1776951 100 pc(s)

User & Safety Instructions

User & Safety Instructions 566767 Phoenix Contact Pin housing PCB MSTBV Total number of pins 9 Contact spacing: 5 mm 1776951 100 pc(s)

Description

Header, Nominal current: 12 A, Rated voltage (III/2): 320 V, Number of positions: 9, Pitch: 5 mm, Color: green, Contact surface: Tin, Assembly: Soldering
