Image similar
Phoenix Contact Socket housing cable TFMC Total number of pins 2 Contact spacing: 3.50 mm 1772634 50 pc(s)
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
2
Series
TFMC
CS
3.50 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 50 pc(s))
Total (€ 5.50 / piece)
€ 275.00
incl. VAT
14-day return policy included
Highlights & Details
Printed-circuit board connector TFMC 1,5/ 4-ST-3,5
- Content: 50 pc(s)
- No. of rows: 2
- Total number of pins: 2
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
2
- Connector system
wire-to-board
- Series
TFMC
- Features
+ push-in spring bracket
- CS
3.50 mm
- Total number of pins
2
- Width
22.90 mm
- Nominal current
8 A
- Nominal current - rounded value
8 A
- Content
50 pc(s)
- AWG max.
16
- AWG (min.)
24
- Stripping length (max.)
10.00 mm
- Dim
(L x W x H) 14.80 x 22.90 x 15.70 mm
- Connection
Spring-loaded terminal
Plug
- Manufacturer part #
1772634
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
160 V
- Height
15.70 mm
- Length
14.80 mm
- max. cross section
1.5 mm²
- Min. cross section
0.2 mm²
- Type
TFMC 1,5/ 4-ST-3,5
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 717283 Phoenix Contact Socket housing cable TFMC Total number of pins 2 Contact spacing: 3.50 mm 1772634 50 pc(s)
User & Safety Instructions
User & Safety Instructions 717283 Phoenix Contact Socket housing cable TFMC Total number of pins 2 Contact spacing: 3.50 mm 1772634 50 pc(s)
Description
Plug component, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 4, Pitch: 3.5 mm, Connection method: Spring-cage conn., Color: green, Contact surface: Tin
