Name: RAFI 1.30.070.201/1002 RAFIX 16 130070201/1002 Pushbutton stackable Tappet Transparent 1 pc(s) Piece
Brand: RAFI
SKU: 702528
Availability: InStock

Rectangular yellow push button with a black frame and silver connection housing. Textual notes on electrical specifications.

Technical drawing of a switch with dimensions: Overall size 70x25x44, Thread M16x1, Length 24.95 ±0.5 mm, Width 19.30 mm.

1/2

Image similar

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

18 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 12.10 / piece)

€ 12.10

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

RAFI 1.30.070.201/1002 RAFIX 16 130070201/1002 Pushbutton stackable Tappet Transparent 1 pc(s) Piece

Our service for you

Technical specifications

Shock strength according to IEC 68-2-27
Climatic stability: constant climate acc. to IEC 68-2-3 and 2-30; Changing climate acc. to IEC 68-2-14 and 2-33

Packaging type: Piece

Product type: Pushbutton

Switch/button features: stackable

Lighting type: Area illumination

Bulb type: LED (monochrome)

Operation type: Tappet

Factory colour: Transparent

Case colour: Clear

Print motif: None

Connection: External contact

Shape: Square / stackable

Front panel thickness: 0.5 - 5 mm

Functions: Contact

Recess diameter: 16.2 mm

Type: Push buttons

Min. temperature: -25 °C

Max. temperature: +70 °C

Width: 25 mm

Height: 25 mm

Content: 1 pc(s)

Dim: (W x H) 25 mm x 25 mm

RoHS-compliant: Yes

Type: RAFIX 16 130070201/1002

Type: 130070201/1002

Temperature range: (Unlit): -25 - +70 ° C / (lit) -25 - +55 °C
