Raspberry Pi® RPI CM5 IO BOARD I/O module Compatible with (development kits): Raspberry Pi®
EAN:
Part number:
Item no:
Total (€ 26.99 / piece)
€ 26.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
I/O module
- Suitable for
Raspberry Pi® Compute Modul 5
- Length
160 mm
- Width
90 mm
- Suitable for
Raspberry Pi®
- Interfaces
Ethernet
- Tool type
I/O module
- Internal ports
GPIO (40-pin)
- Compatible with
Raspberry Pi®
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3356680 Raspberry Pi® RPI CM5 IO BOARD I/O module Compatible with (development kits): Raspberry Pi®
Description
The Raspberry Pi Compute Module 5 IO Board provides a starting point for those looking to integrate Raspberry Pi Compute Module 5 into products, and also serves as an alternative to Raspberry Pi form factor for industrial applications. It transmits all the peripheral interfaces of the Compute Module 5 to the standard ports of the Raspberry Pi 5 (with full-size HDMI instead of micro-HDMI), so that development engineers can fully exploit the processing and interface capabilities of our modular flagship product.
This text is machine translated.
This text is machine translated.
Features
- Form factor 160 mm × 90 mm
- Standard 40-pin GPIO connector
- Gigabit Ethernet RJ45 with PoE+ HAT+ support
- 2 × USB 3 sockets
- MicroSD card slot for CM5 Lite modules
- M.2 M-Key PCIe socket
- 4-pin fan connector
- 2 × MIPI DSI/CSI-2 FPC connector (22-pin cable with 0.5 mm distance)
- Raspberry Pi HAS+ connector
- RTC battery connection
- Full-size 2 × HDMI 2.0 connections
- External +5V-USB-C power supply
- Power button to wake up and shut down the Compute Module 5
