RED MAGNETICS ITS-LS2924B-Z-12VDC Solenoid attracting 0.2 N/mm 10.22 N/mm 12 V DC 4.5 W
Product type
Solenoid
Type
attracting
Connection
Open end cable
Nominal voltage
12 V DC
Nominal lift
15 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 17.99 / piece)
€ 17.99
incl. VAT
14-day return policy included
Highlights & Details
Metal bracket magnet
Our service for you
Technical specifications
- Product type
Solenoid
- Type
ITS-LS2924B-Z-12VDC
- Type
attracting
- Connection
Open end cable
- Cable length
20.00 cm
- Nominal voltage
12 V DC
- Nominal lift
15 mm
4.5 W
- Initial force
0.2 N/mm
- Peak force
10.22 N/mm
- Temperature limit
130 °C
- Weight
122 g
- Thread size
M3
- Length
40 mm
- Width
29.5 mm
- Height
24.2 mm
- Dim
(L x W x H) 40 x 29.5 x 24.2 mm
- RoHS-compliant
Yes
- Type
pulling
- Nominal voltage (details)
12 V DC
- Type
ITS-LS2924B-Z-12VDC
- Fitting method
M3
Documents & Downloads
Datasheet
Datasheet 502352 RED MAGNETICS ITS-LS2924B-Z-12VDC Solenoid attracting 0.2 N/mm 10.22 N/mm 12 V DC 4.5 W
User & Safety Instructions
User & Safety Instructions 502352 RED MAGNETICS ITS-LS2924B-Z-12VDC Solenoid attracting 0.2 N/mm 10.22 N/mm 12 V DC 4.5 W
Description
Economical and light frame construction. Includes damping ring for damping the impact housing. Open construction with closed brace.
Hints
Weight specification includes plunger core
