Name: Rohde & Schwarz R&S®NGC102 Bench PSU (adjustable voltage) 0 - 32 5 A (max.) 100 W USB remote controlled No. of outputs 2
Brand: Rohde & Schwarz
SKU: 3130869
Availability: BackOrder

A digital two-channel power supply unit displays on its screens: CH1 32.000V, 1.528A, CH2 9.000V, 5.000A. Various control elements are visible.

Back of a power supply unit with multiple ports, including LAN, IEEE-488, and USB. Inscription: 'Engineered in Germany'.

1/2

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 1,695.00 / piece)

€ 1,695.00

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Rohde & Schwarz NGC102 2-CH DC power supply 100 W, 2x 32 V, 5 A

No. of outputs 2 x
0 - 32 / 5 A (max.)
0 - 32 V / 5 A (max.)
100 W
USB
remote controlled

Technical specifications

Type: R&S®NGC102

Product type: Bench PSU (adjustable voltage)

No. of outputs: 2 x

: 100 W

Technology: Linear regulated PSU

Interfaces: USB

Features: remote controlled

Dim: (L x W x H) 291 x 222 x 97 mm

: Manufacturer's standards (no certificate)

Weight: 2.6 kg

Output voltage (max.): 32 V

Output voltage (min.): 0 V

Output voltage 2 (max.): 32 V

Output voltage 2 (min.): 0 V

Max. output current: 5 A

Output current 2 (max.): 5 A

Width: 222 mm

Height: 97 mm

Length: 291 mm

Documents & Downloads

Datasheet

Datasheet 3130869 Rohde & Schwarz R&S®NGC102 Bench PSU (adjustable voltage) 0 - 32 5 A (max.) 100 W USB remote controlled No. of outputs 2

User & Safety Instructions

User & Safety Instructions 3130869 Rohde & Schwarz R&S®NGC102 Bench PSU (adjustable voltage) 0 - 32 5 A (max.) 100 W USB remote controlled No. of outputs 2

Description

The feature-rich R&S®NGC100 family consists of three models, all with a maximum total power of up to 100 W and a continuous voltage range from 0 V to 32 V. The single-channel R&S®NGC101 delivers a maximum of 10 A, the two-channel R&S®NGC102 a maximum of 5 A and the three-channel R&S®NGC103 a maximum of 3 A per channel. The outputs are galvanically isolated, floating and protected against overload and short circuit. The electrically equivalent outputs of the two- and three-channel models make it possible for the user to switch several outputs in parallel or in series, in order to increase the voltage or current to up to 96 V or 10 A. The synchronization of the outputs, the performance of curve shape tests and the recording of data for detailed analyzes are a breeze with the R&S®NGC100 power supply series. An intuitive operating concept navigates the user quickly through the menus. All R&S®NGC100 power supplies have remote sense connectors, an external trigger input, an analog control interface, a USB and a LAN interface.
