Sauter FK 50 Digital Force Gauge N/A
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 289.92 / piece)
€ 289.92
plus VAT.
Only 4 Piece(s) available
Highlights & Details
Digital force meter FK 50
- Location-dependent switch display
- Robust Push/Pull Force Gauge for simple measurement
- Data Sampling Rate: 1000 Hz.
- Accuracy: 0.5 % of Capacity
- Overload Protection 200 % of full scale
Technical specifications
- Power supply (details)
9 V DC
- Dim
(L x W x H) 195 x 84 x 35 mm
- Weight
600 g
- Height
35 mm
- Length
195 mm
- Width
84 mm
- Force reading range
50 N (max.)
Manufacturer's standards (no certificate)
- Force reading range (max.)
50 N
- Resolution
0.02 N
- Reading frequency
1000 Hz
- Accuracy (details)
0.5 %
- Product type
Force gauge
Documents & Downloads
Datasheet
Datasheet 123946 Sauter FK 50 Digital Force Gauge N/A
User & Safety Instructions
User & Safety Instructions 123946 Sauter FK 50 Digital Force Gauge N/A
Information
Information 123946 Sauter FK 50 Digital Force Gauge N/A
Conformity certificate
Conformity certificate 123946 Sauter FK 50 Digital Force Gauge N/A
Description
The simple operation and the display position-dependent switching feature proves this standard device. Ideal for all applications where no logging must be done through an interface. For tensile and compressive forces with peak function.
Features
- Peak-hold mode
- Display in N, lb, kg, oz
- Tara functional
- backlighting
- Adaptable to benches
- Overload protection 200% of Max • 1,000 readings per second
- Optional battery operation (6) x AA
- power supply operation.
Scope of delivery
- 5 Standard Attachment
- Extension rod 90 mm
- Power supply
- Operating instructions.
