Name: Siemens 3SU1150-7AF88-1QA0 Coordinate switch 500 V IP65, IP67 1 pc(s)
Brand: Siemens
SKU: 1730800
Availability: BackOrder

Joystick switch with chrome-plated housing and black lever, suitable for industrial applications and control systems.

View of a cable car station with an orange gondola in the Alps. Control panel in the foreground shows colourful buttons.

A chemical structural formula shows an ionic molecule. Three NO₃ groups are bonded to a central S⁶⁺ ion.

Technical drawing of a switch. Dimensions: 40 mm width, 105 mm length. Front and side views, along with connection diagram, are shown.

1/4

Image similar

Product type

Coordinate switch

Switching voltage

500 V

Functions

momentary

Type

Without mechanical locking

Factory colour

Black

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 12 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 115.96 / piece)

€ 115.96

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Actuator material: plastic
Maximum Auslenkwinkel: 30°
Switching frequency / maximum [1/h]: 3600

Product type: Coordinate switch

Functions: momentary

Type: Without mechanical locking

Factory colour: Black

Switch position: 4P

Switching voltage: 500 V

Min. temperature: -25 °C

Max. temperature: +70 °C

Width: 40 mm

Height: 40 mm

Recess diameter: 22.3 mm

Durability: 500000

Electrical lifespan: 1000 0000

: IP65
IP67

Content: 1 pc(s)

Dim: (W x H) 40 mm x 40 mm

RoHS-compliant: Yes

Type: 3SU1150-7AF88-1QA0

Weight: 0.1800 kg

: 4

: 4

: 22.3 mm

: 4

: 4

: TRUE

: Other

: FALSE

: IP65/IP67

: 0

: FALSE

: Other

: TRUE

: FALSE

: 71.3 mm

: 0

: Other

UKCA: yes
