Siemens 4AC32140 Bell transformer 8 V, 12 V, 24 V 2 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 61.99 / piece)
€ 61.99
incl. VAT
14-day return policy included
Technical specifications
- Output active power max.: 14 W
- Power loss max.: 10.5 W
- Output current max.: 2 A
- Number of wide division units: 2
- Product type
Bell transformer
- Mounting type
DIN rail
- Operating voltage
230 V
- Output voltages
8 V
12 V
24 V
- Max. nominal current
2 A
- Width
36 mm
- Height
64 mm
- Length
90 mm
- Dim
(L x W x H) 90 x 36 x 64 mm
36
64 mm
Standard bell ringing transformer
FALSE
TRUE
2 A
90 m
14 W
2
TRUE
230 V
8 V
12 V
24 V
2 A
1.3 A
0.6 A
TRUE
10.5 W
FALSE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1699835 Siemens 4AC32140 Bell transformer 8 V, 12 V, 24 V 2 A
Datasheet 1699835 Siemens 4AC32140 Bell transformer 8 V, 12 V, 24 V 2 A
User & Safety Instructions
User & Safety Instructions 1699835 Siemens 4AC32140 Bell transformer 8 V, 12 V, 24 V 2 A
Description
Bell transformer, 14VA Primary 230-240 V AC, 50 Hz, secondary 8 V, 12V, 24V AC With PTC fuse, 2MW++ Bell transformers for controlling bells, gongs, door openers or remote control switches. A typical application for these bell transformers is short-time use, as occurs with bells, gongs, door openers or remote control switches in residential buildings. The rated secondary voltages range from 4 V to 24 V AC. Siemens bell transformers are protected against short circuits and moderate overload by a PTC resistor. Whether for infrastructure or for industrial requirements, Siemens supplies bell transformers for all applications and every application area. Key features of the network devices from Siemens: 1. User-friendly and easy installation and connection technology. 2. Reliable safety during installation with standard touch protection. 3. Integrated short-circuit and overload protection. 4. Optimized safe power supply technology for your safety – only from Siemens. www.siemens.com/lowvoltage. Siemens offers a comprehensive portfolio of protection, switching, measuring and monitoring devices, distribution systems as well as switches and sockets for safe and efficient electrical infrastructure in buildings and industry.
