Image similar
Image similar
TDK-Lambda KMS60A-5 AC/DC PSU (print) 5 V 12 A 60 W
EAN:
Part number:
Item no:
Sales and shipping:
Number
Total (€ 105.03 / piece)
€
Highlights & Details
15-60W AC-DC Medical PCB Mount Power Supply
- Medical approvals
- Operating height up to 5,000 meters
- 4,000 V AC (2 x mops) between input and output
- Very low idle consumption
- Protection class II devices / no earth connection (PE) required
Technical specifications
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
370 V DC
- Max. output current
12 A
- Output current (max.) - rounded
12 A
- Min. input voltage
90 V AC
120 V DC
- Dim
(L x W x H) 89 x 63.5 x 27 mm
- Output voltage (max.)
5 V
60 W
- Protection class
II
- Operating temperature (max.)
80 °C
- Operating temperature (min.)
-40 °C
- Weight
280 g
- Width
63.5 mm
- Height
27 mm
- Length
89 mm
- Type
KMS60A-5
Documents & Downloads
Warranty Terms
Warranty Terms 2358671 TDK-Lambda KMS60A-5 AC/DC PSU (print) 5 V 12 A 60 W
Description
This small and light enclosed KMS-A power supply modules for PCB mounting have a medical approval and are therefore ideally suited for a variety of medical applications, e.g. in the dental and homecare field, but also for testing and measuring technology as well as for the radio and industrial sector. All devices of the KMS-A series have a single output and have 15-60 W output power. Their range of output voltages covers all common values between 5Vdc and 24Vdc. As protection class II devices, the KMS-A power supplies do not require a ground connection (PE).
