Buy Testboy TV 350 Anemometer 0.8 up to 30 m/s

Handheld device for measuring air velocity, temperature and humidity. Display shows '23.2°C', '35.5°C' and '02.45 m/s'.

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

2 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 251.26 / piece)

€ 251.26

plus VAT.

Only 2 Piece(s) available

Report legal concerns

Technical specifications

Air speed: 0.80 to 30.0 m/s; 1.4 to 108.0 km/h; 0.9 to 67.0 mil/h; 80 to 5900 ft/m; 1.3 to 98.5 ft/s, 0.8 to 58.0 knots
Air temperature: - 20 to +60°C; - 4 to 140 °F.
Relative humidity: From 20% to 90%
Air flow: 0 to 9999 m³/sec; 0 to 99990 m³/min; 0 to 99990 ft ³/min.

Product type: Anemometer

Temperature reading range: -20 up to +60 °C

Dim: (L x W x H) 40 x 85 x 170 mm

Weight: 230 g

Temperature reading range (max.): +60 °C

Temperature reading range (min.): -20 °C

Air speed reading range (max.): 30 m/s

Air speed reading range (min.): 0.8 m/s

Width: 85 mm

Height: 170 mm

Length: 40 mm

Power supply (details): 1 x 9 V battery

Documents & Downloads

Datasheet

Datasheet 2885790 Testboy TV 350 Anemometer 0.8 up to 30 m/s

User & Safety Instructions

User & Safety Instructions 2885790 Testboy TV 350 Anemometer 0.8 up to 30 m/s

Description

The digital vane anemometer Testboy TV 350 is the ideal assistant for heating, ventilation and air conditioning systems. In addition to the wind speed from 0.8 to 30.0 m/s, it is thus possible to measure the relative air humidity from 20 to 90 %, the air temperature from -20 to +60 °C, the air flow from 0 to 9999 m³/sec, the dew point temperature and the air volume. Measurements can be recorded via the integrated USB interface and the software supplied. Of course, it can be displayed in internationally used measuring units such as meters, kilometers, feet, miles and knots.
