Name: TOOLCRAFT TO-9621810 Fibre optic tool Incl. cable cutter, incl. cable stripper 0 up to 25 mm
Brand: TOOLCRAFT
SKU: 3207270
Availability: InStock

Highlights & Details

TOOLCRAFT Fiber Optics Preparation Kit

Fibre three-head pipe cutter: Makes clean, right-angled and burr-free ring cuts
Adjustable cable slot and ring cutters for fiber optic cables: Perform slit and ring cuts for different diameters of fiber optic cables, buffer tubes and sheathing.
Stripping pliers for fiber-glass cable: Thanks to the safety lock, the tool can be stowed away easily when not in use
Fiber Optic scissors suitable for: Kevlar made of glass fiber cable, aramide yarn, soft cable, electrical tape

Technical specifications

Three-head fiber pipe cutter: Length: 215mm/ weight: 206g, capacity: Tube OD~Ø25mm, for plastic fiber micro-channel tube: 0-8mm, 9-18mm, 19-25mm
Adjustable slit and ring fiber optic cable stripper: Length: 73mm/weight: 22g, slit stripping and rotation insulation: Ø1.2~Ø3.2mm/Ø3.2~Ø6.4mm, replaceable and reversible slit V-block
Fibre optic cable stripper: Length: 160mm / weight: 120g, outer sheath (strips 2.0~3.0mm), buffer insulation (strips 900μm), acrylate coating (strips 250μm)
Fiber shears: Length: 147mm / Weight: 61g, thickness of blade: 2.4 mm, material of blade: Stainless steel

Product type: Fibre optic tool

Suitable for: PVC tubes

Operating range (diameter): 0 up to 25 mm

Working area diameter (min.): 0 mm

Operating range (diameter) (max.): 25 mm

Material: Stainless steel

Material properties: rust-proof

Features: Incl. cable cutter
incl. cable stripper

Plastic free packaging: Plastic-free packaging

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3207270 TOOLCRAFT TO-9621810 Fibre optic tool Incl. cable cutter, incl. cable stripper 0 up to 25 mm

Warranty Terms

Warranty Terms 3207270 TOOLCRAFT TO-9621810 Fibre optic tool Incl. cable cutter, incl. cable stripper 0 up to 25 mm

Description

With fiber three-head pipe cutter
Ideal for cutting or scoring PVC, CPVC, HDPE and other plastic pipes

Adjustable slide & ring fiber optic stripper
Adjustable blade depth for precise stripping settings.

Fibre optic wire stripper
Angled jaw leads the fiber into the 3. Hole to prevent accidentally cutting the fiber

Fiber-optic shears
Sharp and completely serrated edges increase the cutting ability

This text is machine translated.
